Zoro Select Plate Caster, Swivel, Rubber, 2 13/16"H LPA-TPA 50KF - main

Plate Caster, Swivel, Rubber, 2 13/16"H

  • Mfr # LPA-TPA 50KF

  • Zoro # G214811048

product price:  $18.75
/ea

Key Features

Features
Minimum Swivel Head Play and Smooth Rolling Characteristic and Increased Service Life Due to the Special Dynamic Blickle Riveting Process, Synthetic Thread Guard Large, Tread Contains Oil, may Stain Sensitive Surfaces
Wheel Dia.
51 mm
Caster Frame Material
Steel
Mounting Bolt Dia.
6 mm
Caster Sub-Type
Swivel
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LPA-TPA 50KF
Zoro #
G214811048
UPC #
-
Country of Origin
Germany

Dimensions

Wheel Dia.
51 mm
Mounting Bolt Dia.
6 mm
Mounting Height
71 mm
Wheel Width
19 mm
Mounting Plate Length
60 mm
Outside Slot Spacing - Width
48 mm
Outside Slot Spacing - Length
48 mm
Inside Slot Spacing - Length
38 mm
For Axle Dia.
6 mm
Overall Wheel Width
19 mm
Inside Slot Spacing - Width
38 mm
Mounting Plate Width
60 mm
Mounting Plate Thickness
2 mm
Hub Length
23 mm

Details

Features
Minimum Swivel Head Play and Smooth Rolling Characteristic and Increased Service Life Due to the Special Dynamic Blickle Riveting Process, Synthetic Thread Guard Large, Tread Contains Oil, may Stain Sensitive Surfaces
Item
Plate Caster
Caster Frame Material
Steel
Caster Sub-Type
Swivel
Swivel Construction
Kingpin
Number of Mounting Holes
4
Frame Finish
Zinc Plated
Caster Mounting Type
Plate
System of Measurement
Metric
Non-Marking
Yes
Number of Wheels
1
Caster Brake Type
No Brake
Wheel/Tread Color
Gray
Core Color
Silver
Series
TPA
Operating Temperature - Minimum
-20 Degrees C
Mounting Plate Shape
Rectangle
Mounting Hole Type
Slot
For Surface Type
Asphalt, Ceramic, Grease, Oil, Rubber, Steel, Tile, Vinyl, Wood
Caster Features
Corrosion-Resistant, Debris-Resistant, Maintenance Free, Quiet-Roll
Frame Construction
Pressed
Wheel Bearing Material
Steel
Wheel Core Material
Polypropylene
Includes Thread Guards
Yes
Wheel Hardness Rating
85 Shore A
Wheel Core Type
Solid
NSF Listed
No
Load Capacity - Maximum
110 lb
Operating Temperature - Maximum
60 Degrees C
Tread Shape
Standard
Wheel Bearing Type
Ball
Wheel/Tread Material
Rubber
Swivel Raceway Type
Double Ball

Description

Swivel, Plate Caster, Wheel Dia. 51 mm, Wheel Width 19 mm, Wheel/Tread Material Rubber, Wheel Core Material Polypropylene, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
