Sheet Metal Screw, #10 x 1 in, Black Phosphate Steel Flat Head Phillips Drive, 50 PK
Mfr # 9146PK
Zoro # G5138244
CAD Available
product price:Â $7.65
/pk 50, $0.15/eaKey Features
Flat Head
Phillips Drive
Pointed Tip
CAD Drawing
System of Measurement
Inch
Screw Size
#10
Material
Steel
Finish
Black Phosphate
Materials for Use With
Metal
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
9146PK
Zoro #
G5138244
UPC #
841213008397
Country of Origin
Taiwan, Province of China
Dimensions
Screw Size
#10
Fastener Length
1 in
Head Dia.
1/2 in
Head Height
0.188 in
Head Width
0.5 in
Overall Length
1 in
Washer Outside Diameter
0.5 in
Maximum Head Width
1/2 in
Maximum Head Height
3/16 in
Details
System of Measurement
Inch
Head Type
Flat
Drive
Phillips
Tip Type
Pointed
Material
Steel
Finish
Black Phosphate
Materials for Use With
Metal
Thread Style
Fully Threaded
Item
Sheet Metal Screw
Type
Sheet Metal Screw
Includes Nut
Nut Not Included
Includes Washer
Yes
Pack Size
Small
Thread Type
Coarse
CAD Available
Yes
Description
Sheet Metal Screw, Head Type Flat, Finish Phosphate, Material Steel, Screw Size #10, Fastener Length 1 in, Head Width 0.5 in, Head Height 0.188 in, Dimensional Standards Not Applicable, For Maximum Material Thickness Not Applicable, Pack Size Small, Minimum Head Height Not Applicable, Minimum Head Width Not Applicable, Maximum Head Height 3/16 in, Maximum Head Width 1/2 in, System of Measurement Inch, Drive Phillips, For Use in Systems Not Applicable, Includes Nut Nut Not Included
