  6. Swivel Plate Caster, 300 lb., Ball, Red
Zoro Select Swivel Plate Caster, 300 lb., Ball, Red P12SX-RP040B-12-001 - main

Swivel Plate Caster, 300 lb., Ball, Red

  • Mfr # P12SX-RP040B-12-001

  • Zoro # G7210567

product price:  $68.25
/ea

Key Features

Caster Stem Type
No Stem/Plate Included
Core Color
Gray
Load Rating
300 lb
Standards
ANSI ICWM
Caster Plate Hole Pattern
C
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
P12SX-RP040B-12-001
Zoro #
G7210567
UPC #
-
Country of Origin
China

Dimensions

Stem Dia.
No Stem
Mounting Bolt Dia.
5/16 in
Wheel Width
1 1/4 in
Wheel Dia.
4 in
Overall Height
5-1/16in
Mounting Plate Size
2-1/2in x 3-5/8in
Mounting Height
5 1/8 in
Swivel Radius
3-1/4 in
Mounting Plate Length
2 1/2 in
Inside Slot Spacing - Width
1.75 in
Outside Slot Spacing - Length
3.063 in
Mounting Plate Thickness
1/8in
Inside Slot Spacing - Length
2.813 in
Overall Wheel Width
1 1/4 in
Outside Slot Spacing - Width
1.75 in
For Axle Dia.
3/8 in

Details

Caster Stem Type
No Stem/Plate Included
Core Color
Gray
Load Rating
300 lb
Standards
ANSI ICWM
Caster Plate Hole Pattern
C
Includes
Dust Cover, Thread Guard
Caster Temp. Range Available
Yes
Frame Finish
Polished
Outside Bolt Hole Spacing
1-3/4 in x 3-1/16 in
Application
Food Service Racks and Cases, Hotel Equipment, Institutional Equipment, Laundry Trucks, Stock Carts
Inside Bolt Hole Spacing
1-3/4 in x 2-13/16 in
Caster Sub-Type
Swivel
Thread Guards
Yes
Number of Wheels
1
Caster Frame Material
Stainless Steel
Caster Brake Included
No
Non-Marking
Yes
Wheel Color
Gray
Item
Swivel Caster
Extended Lead
No
Tread Color
Gray
System of Measurement
Inch
Tread
Standard
Replacement Wheel
Mfr. No. P-PRP-040x013/038K
Caster Brake Type
No Brake
Caster Mounting Type
Plate
Swivel Construction
Kingpin
Load Rating Range
Light-Medium Duty
Includes Thread Guards
No
Wheel/Tread Hardness Rating
Firm
Number of Mounting Holes
4
Swivel Raceway Type
Double Ball
Swivel Lock Type
No Lock Included
Wheel Bearing Type
Ball
Wheel Core Material
Polypropylene
Tread Shape
Standard
Wheel/Tread Material
Thermoplastic Rubber
Wheel/Tread Color
Gray
Load Capacity
300 lb
ESD Conductive
No
Series
P12X Series
Resistant To
High Chemical Resistance To Many Aggressive Substances
Load Capacity - Maximum
300 lb
Wheel Hardness Rating
90 Shore A
Mounting Hole Type
Slot
Caster Features
Corrosion-Resistant
Wheel Core Type
Solid
For Surface Type
Asphalt, Ceramic, Grease, Oil, Rubber, Steel, Tile, Vinyl, Wood
Mounting Plate Shape
Rectangle
Wheel Bearing Material
Steel
Operating Temperature - Minimum
-30 Degrees F
Operating Temperature Range
-30 Degrees to 300 Degrees F
Operating Temperature - Maximum
300 Degrees F

Description

Swivel, Plate Caster, Load Rating 300 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 1 1/4 in, Wheel/Tread Material Rubber, Wheel Core Material Polyolefin, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
