  11. Swivel Plate Caster, Delrin, Steel
Zoro Select Swivel Plate Caster, Delrin, Steel P21S-PRP040R-14 - main

Swivel Plate Caster, Delrin, Steel

  • Mfr # P21S-PRP040R-14

  • Zoro # G3420672

product price: $25.69
/ea

Key Features

Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Thermoplastic Rubber
Caster Brake Type
No Brake
Wheel Dia.
4 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
P21S-PRP040R-14
Zoro #
G3420672
UPC #
-
Country of Origin
China

Dimensions

Wheel Dia.
4 in
Wheel Width
2 in
Mounting Height
5 5/8 in
Mounting Plate Size
4in x 4-1/2in
Mounting Plate Thickness
1/4in
Mounting Bolt Dia.
3/8 in
Overall Height
5-5/8in
Stem Dia.
No Stem
Swivel Radius
3-3/8 in
Mounting Plate Width
4 in
Inside Slot Spacing - Width
2.625 in
Overall Wheel Width
2 in
Mounting Plate Length
4 1/2 in
Outside Slot Spacing - Width
3 in
Outside Slot Spacing - Length
3.625 in
Inside Slot Spacing - Length
3 in
Bolt Hole Spacing - Length
2.625 in
For Axle Dia.
1/2 in

Details

Item
Swivel Caster
Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Thermoplastic Rubber
Caster Brake Type
No Brake
Load Rating
300 lb
Caster Mounting Type
Plate
Wheel Bearing Type
Roller
Wheel/Tread Color
Gray
Wheel Hardness Rating
90 Shore A
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Core Color
Gray
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Inside Bolt Hole Spacing
3 in x 3 in
Caster Plate Hole Pattern
B
Caster Temp. Range Available
Yes
Wheel Color
Gray
Caster Brake Included
No
Thread Guards
No
Standards
RoHS, ICWM, NSF
Frame Finish
Zinc Plated
Caster Stem Type
No Stem/Plate Included
Extended Lead
No
Replacement Wheel
Mfr. No. P-RP-040x020/050R
Application
Retail, Industrial, Commercial
Tread
Standard
Tread Color
Gray
Includes Thread Guards
No
Wheel/Tread Hardness Rating
Firm
Load Rating Range
Light-Medium Duty
Swivel Lock Type
No Lock Included
Swivel Construction
Kingpin
Wheel Core Material
Polypropylene
Swivel Raceway Type
Double Ball
Series
P21 Series
Resistant To
High Chemical Resistance To Many Aggressive Substances
Accessories
Optional: P-DL21-14 (Directional Lock)
Load Capacity
300 lb
ESD Conductive
No
Load Capacity - Maximum
300 lb
Compatible With
P-RP-040X020/050R
Caster Features
Debris-Resistant
Mounting Plate Shape
Rectangle
Wheel Bearing Material
Steel
Mounting Hole Type
Slot
Wheel Core Type
Solid
For Surface Type
Asphalt, Ceramic, Grease, Oil, Rubber, Steel, Tile, Vinyl, Wood
Operating Temperature Range
-45 Degrees to 180 Degrees F
Operating Temperature - Maximum
180 Degrees F
Operating Temperature - Minimum
-45 Degrees F

Description

Swivel, Plate Caster, Load Rating 300 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 2 in, Wheel/Tread Material Rubber, Wheel Core Material Polyolefin, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
