Swivel Plate Caster, Glass Nylon, 8 in, 1250 lb

  • Mfr # P21S-NG080R-14

  • Zoro # G2238241

product price:
$
51.99
/ea

Key Features

Frame Finish
Zinc Plated
Caster Sub-Type
Swivel
Caster Brake Included
No
Core Color
Black
Load Rating
1250 lb
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
P21S-NG080R-14
Zoro #
G2238241
UPC #
-
Country of Origin
China

Dimensions

Overall Height
9-1/2"
Wheel Dia.
8 in
Wheel Width
2 in
Mounting Bolt Dia.
3/8 in
Stem Dia.
No Stem
Mounting Height
9 1/2 in
Mounting Plate Size
4in x 4-1/2in
Swivel Radius
6-5/8 in
Inside Slot Spacing - Width
2.625 in
Inside Slot Spacing - Length
3 in
For Axle Dia.
1/2 in
Outside Slot Spacing - Width
3 in
Mounting Plate Length
4 in
Outside Slot Spacing - Length
3.625 in
Mounting Plate Thickness
7/32 in
Overall Wheel Width
2 in

Details

Frame Finish
Zinc Plated
Caster Sub-Type
Swivel
Caster Brake Included
No
Core Color
Black
Load Rating
1250 lb
Thread Guards
No
Caster Plate Hole Pattern
B
Item
Plate Caster
Standards
ANSI ICWM
Outside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Inside Bolt Hole Spacing
3 in x 3 in
Wheel Color
Black
Caster Stem Type
No Stem/Plate Included
Caster Temp. Range Available
Yes
Caster Frame Material
Steel
Number of Wheels
1
Includes
Complete Caster
Caster Brake Type
No Brake
System of Measurement
Inch
Application
Retail, Industrial, Commercial, Corrosion Resistance
Non-Marking
Yes
Tread Color
Black
Tread
Standard
Replacement Wheel
Mfr. No. P-NG-080x020/050R
Caster Mounting Type
Plate
Wheel Core Material
Nylon
Wheel/Tread Hardness Rating
Hard
Load Rating Range
Medium-Duty
Number of Mounting Holes
4
Swivel Construction
Kingpin
Includes Thread Guards
No
Swivel Lock Type
No Lock Included
Tread Shape
Standard
Swivel Raceway Type
Double Ball
Wheel Bearing Type
Roller
Wheel/Tread Material
Nylon
Wheel/Tread Color
Black
Extended Lead
No
Resistant To
High Chemical Resistance To Many Aggressive Substances
ESD Conductive
No
Accessories
Optional: P-DL21-14 (Directional Lock)
Load Capacity
1250 lb
Series
P21 Series
Load Capacity - Maximum
1,250 lb
Wheel Hardness Rating
85 Shore D
Mounting Plate Shape
Rectangle
For Surface Type
Asphalt, Ceramic, Grease, Oil, Rubber, Steel, Tile, Vinyl, Wood
Caster Features
Corrosion-Resistant
Wheel Bearing Material
Steel
Wheel Core Type
Solid
Mounting Hole Type
Slot
Operating Temperature Range
-20 Degrees To 250 Degrees F

Description

Swivel, Plate Caster, Load Rating 1250 lb, Swivel Lock Type No Lock Included, Wheel Dia. 8 in, Wheel Width 2 in, Wheel/Tread Material Nylon, Wheel Core Material Nylon, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
