  11. Swivel Plate Caster, Phenolic, 3 in, 350 lb
Zoro Select Swivel Plate Caster, Phenolic, 3 in, 350 lb 02TM03101S002 - main

Swivel Plate Caster, Phenolic, 3 in, 350 lb

  • Mfr # 02TM03101S002

  • Zoro # G4801711

product price: $13.55
/ea

Key Features

Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Phenolic
Caster Brake Type
No Brake
Wheel Dia.
3 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
02TM03101S002
Zoro #
G4801711
UPC #
190735900581
Country of Origin
China

Dimensions

Wheel Dia.
3 in
Wheel Width
1 1/2 in
Mounting Height
4 1/4 in
Mounting Plate Size
3 3/4 in x 4 1/2 in
Mounting Plate Thickness
5/32in
Mounting Bolt Dia.
5/16 in
Overall Height
4-1/4in
Stem Dia.
No Stem

Details

Item
Plate Caster
Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Phenolic
Caster Brake Type
No Brake
Load Rating
350 lb
Wheel Bearing Type
Roller
Wheel/Tread Color
Black
Wheel Hardness Rating
85 Shore D
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Core Color
Black
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Inside Bolt Hole Spacing
3 in x 3 in
Caster Plate Hole Pattern
B
Standards
ANSI ICWM
Thread Guards
No
Frame Finish
Zinc Plated
Caster Stem Type
No Stem/Plate Included
Extended Lead
No
Caster Temp. Range Available
Yes
Wheel Color
Black
Application
Food Service Racks and Cases, Hospital Equipment, Hotel Equipment, Institutional Equipment, Laundry Trucks, Office Equipment, Stock Carts, Store Fixtures, Utility Carts
Includes
Dust Cover
Replacement Wheel
TM0310106G
Caster Brake Included
No
Wheel/Tread Hardness Rating
Hard
Includes Thread Guards
No
Load Rating Range
300 to 999 lb
Swivel Raceway Type
Double Ball
Swivel Construction
Kingpin
Wheel Core Material
Phenolic
Swivel Lock Type
No Lock Included
Load Capacity - Maximum
350 lb
Compatible With
TM0310106G
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature Range
-40 Degrees to 250 Degrees F
Operating Temperature - Maximum
250 Degrees F

Description

Swivel, Plate Caster, Load Rating 350 lb, Swivel Lock Type No Lock Included, Wheel Dia. 3 in, Wheel Width 1 1/2 in, Wheel/Tread Material Phenolic, Wheel Core Material Phenolic, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
