TL Bushing, 1610, 28 mm B Dia, 1 in L
Mfr # 1610X28MM
Zoro # G310984288
product price: $17.59
/eaKey Features
Bore Bushing Series
1610
Length
1 in
Flange Type
Flangeless
Bushing Type
Taper Lock
Overall Diameter
2.25 in
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
1610X28MM
Zoro #
G310984288
UPC #
00195057565319
Country of Origin
China
Dimensions
Length
1 in
Overall Diameter
2.25 in
Bore Diameter
28 mm
Bolt Circle Diameter
2.13 in
Keyway Height
3.5 mm
Keyway Width
8 mm
Details
Bore Bushing Series
1610
Flange Type
Flangeless
Bushing Type
Taper Lock
System of Measurement
Metric
Item
Taper Lock Bushing
Material
Steel
Includes
(2) Set Screws
Taper
8 Degrees
For Shaft Type
Keyed
Maximum Torque
4,300 in-lb
Description
Taper Lock Bushing, Bushing Type Taper Lock, Bore Bushing Series 1610, Bore Diameter 28 mm, Length 1 in, Bolt Circle Diameter 2.13 in, Bolt Size Not Applicable, System of Measurement Metric, Bushing Diameter Not Applicable, Flange Type Flangeless, Flange Width Not Applicable, For Shaft Type Keyed, Includes (2) Set Screws, Keyway Height 3.5 mm, Keyway Width 8 mm, Length Less Flange Not Applicable, Material Steel, Overall Diameter 2.25 in, Taper 8 Degrees
