White Acetal Copolymer Sheet Stock 24" L x 12" W x 3.500" Thick

  • Mfr # 1NLV5

  • Zoro # G0630411


product price: $547.99
/ea
Free Shipping & Returns

Key Features

Plastic Material
Acetal Copolymer
Plastic Thickness
3.500"
Plastic Width
12"
Plastic Length
24"
Plastic Color
White
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1NLV5
Zoro #
G0630411
UPC #
-
Country of Origin
Multiple

Dimensions

Plastic Thickness
3.500"
Plastic Width
12"
Plastic Length
24"
Width Tolerance
+/-0.25 in
Length Tolerance
+/-0.250 in
Thickness
3.500"
Length
24"
Width
12"
Nominal Size
12 in W x 24 in L
Plastic Length Tolerance
+/-0.250 in
Plastic Width Tolerance
+/-0.25 in

Details

Item
Sheet Stock
Plastic Material
Acetal Copolymer
Plastic Color
White
Max. Temp. (F)
180 Degrees F
Min. Temp. (F)
32 Degrees F
Color
White
Tensile Strength
9,500 psi
Material Color Family
White
Thickness Tolerance
+/-10%
Operating Temp. Range
32 Degrees to 180 Degrees F
Plastic Grouping
Sheet Stock
Material Type
General Purpose
Plastic Properties
Wear Material
Material
Acetal Copolymer
Plastic Thickness Tolerance
+/-10%
Temperature Range
32 Degrees to 180 Degrees F
Corrosion and Chemical Resistance
Fair
Grade
Standard
Minimum Temperature
-40 Degrees F
Plastic Clarity
Opaque
Machinability
100 %
Wear Factor
Excellent
Maximum Temperature
180 Degrees F
Tensile Strength Rating
Good
Impact Strength
1 ft-lb/in
Shape
Rectangle
Plastic Hardness Rating
Hard
Friction Coefficient
0.25
UV Resistant
No
Friction Rating
Slippery
Impact Strength Rating
Poor
Water Absorption
0.2 %
Plastic Hardness
Rockwell M88
Water Absorption Rating
Good
Standards
ASTM 04181, ASTM 06778
Minimum Adhesive Temperature
-30 Degrees F
Plastic Density
1.41 g/cc
Maximum Adhesive Temperature
180 Degrees F
Fabrication
Extruded
FDA Compliance
21 CFR 177.2470
Flexural Modulus
400 ksi
Wear Rate
2.00 x 10^-5 cu mm/N-m
Light Transmission
0 %
Coefficient of Thermal Expansion
6.8 x 10^-5 in/in/ Degrees F
Scratch-Resistant
Scratch-Resistant
Elongation
40 %
Product Form
Sheet
Metal Detectable
Not Metal Detectable
Static-Resistant
Not Static-Resistant
Product Type
Plastic Sheet
Rockwell Hardness
88 HRM
Dielectric Strength
420 V/mil
Shore Hardness
85 Shore D
UV-Resistant
UV-Resistant

Description

Acetal Copolymer Sheet, Acetal Copolymer, Grade Standard, Plastic Length 24 in, Plastic Width 12 in, Plastic Thickness 3.5 in, White, Plastic Clarity Opaque, Tensile Strength 9,500 psi, Impact Strength 1 ft-lb/in, Friction Coefficient 0.25, Water Absorption 0.2 Percent, Temperature Range 32 Degrees to 180 Degrees F, Plastic Density 1.41 g/cc, Plastic Hardness Rockwell M88
