Ring Terminal, 1/4 in Stud Size, 10 AWG, 600 V, Bare Insulated, Bare, Crimp Termination Only
Mfr # MU10-14R/SK
Zoro # G5757446
product price:Â
$
178.99
/pk 500, $0.36/ea
Free Shipping & Returns
Key Features
Terminal Shape
Standard Ring Tongue
Termination Style
Crimp Termination Only
Insulation Color
Bare
Maximum Wire Size
10 AWG
Minimum Wire Size
12 AWG
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- MU10-14R/SK
- Zoro #
- G5757446
- UPC #
- 00054007018827
- Country of Origin
- United States
- Item
- Ring Terminal
- Terminal Shape
- Standard Ring Tongue
- Termination Style
- Crimp Termination Only
- Insulation Color
- Bare
- Insulation Coverage
- None
- Insulation Type
- Bare
- Contact Material
- Copper
- Maximum Voltage
- 600 V
- Maximum Operating Temperature
- 347 Degrees F
- Standards
- CSA Certified, UL Listed
- Seam
- Butted
- Connection Type
- Crimp
- Max. Temp.
- 347 Degrees F
- Terminal Type
- Standard
- Terminal Connection
- Crimp
- Connection Material
- Copper
- Wire Range
- 12 to 10 AWG
- Seam Style
- Butted
- Insulation Material
- None
- Barrel Style
- Brazed
Description
Ring Terminal, Insulation Color Bare, Insulation Material None, Maximum Operating Temperature 347 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 12 AWG, Maximum Wire Size 10 AWG, Termination Style Crimp, Tongue Width 0.53 in, Contact Material Copper, Standards CSA Certified, UL Listed, Barrel Style Brazed, Insulation Type Non-Insulated, Overall Length 0.96 in, Package Quantity 500
