Locking Receptacle, Non-NEMA, 50 A, 250V AC, Single Phase, 2 Pole, Flush Mount, Screw Terminals
Mfr # CS8269
Zoro # G710113097
product price:
$
96.45
/ea
Key Features
NEMA Receptacle Configuration
Non-NEMA
Current Rating
50 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- CS8269
- Zoro #
- G710113097
- UPC #
- 819145029285
- Country of Origin
- Mexico
- Item
- Locking Receptacle
- NEMA Receptacle Configuration
- Non-NEMA
- Current Rating
- 50 A
- Voltage Rating
- 250V AC
- Phase
- Single
- Number of Poles
- 2
- Number of Wires
- 3
- Wire Connection Type
- Screw Terminals
- Grounding
- Grounded
- Housing Color
- Black
- Mount Type
- Flush
- Cover Type
- No Cover
- Flange Type
- Non-Flanged
- Standards
- CSA Certified, UL
- Resistance Properties
- Chemical Resistant, Impact Resistant
- IP Rating
- IP20
- Material
- Nylon
- Wattage
- 12500W
- Number of Female Connectors
- 1
- Application
- Female Connector Wiring Device
- NEMA Enclosure Rating
- 4X, 12, 4
- Shrouded
- Yes
Description
This AC WORKS brand female outlet receptacle (model CS8269) is a durable 50‐amp, 250‐volt locking outlet designed for industrial and commercial applications. It features a 2‐pole, 3‐wire configuration and mounts in a standard CS8269 footprint. The housing is chemical‐resistant and impact‐resistant, providing long‐term reliability in demanding environments. The locking design prevents accidental unplugging, ensuring secure power delivery for heavy‐duty equipment. This receptacle is UL listed (59D4) and CSA certified (81290), meeting high safety and performance standards. It is fully compatible with the CS8265 plug. A 1‐year limited warranty is included.
- CS8269 50A 250V locking female outlet
- Chemical‐resistant and impact‐resistant housing
- Locking design prevents accidental unplugging
- Fast and easy installation
- Compatible with CS8265 plug
- UL 59D4 and CSA 81290 safety approvals
- Includes 1‐year limited warranty
