Flange Threaded Flange, Faced and Drilled, 4" Pipe, Flanged x FNPT, Cast Iron, Class 125
Mfr # 0308003607
Zoro # G3247702
product price:Â $94.99
/eaKey Features
Fitting Connection Type
Flanged x FNPT
Pipe Fitting Material
Cast Iron
Pipe Size (Fittings)
4"
Class
Class 125
Standards
UL: FM Approved: ASME B16.4
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 0308003607
- Zoro #
- G3247702
- UPC #
- 690291021381
- Country of Origin
- United States
Dimensions
- Pipe Size (Fittings)
- 4"
- Pipe Size - Pipe Fitting
- 4 in
- Outside Dia.
- 9"
- Overall Length
- 9 in
- Nominal Pipe Size
- 4 in
- Flange Outside Diameter
- 9 in
- Wire Rope Length
- 9 in
Description
Flange, Flat, 4 in Nominal Pipe Size, Flanged x FNPT, 9 in Flange Outside Diameter, 9 in Overall Length, Cast Iron, Plain, A197, Class Class 125, For Pipe Schedule Not Applicable, 175 psi Maximum Operating Pressure, -20 Degrees to 150 Degrees F, Number of Bolt Holes 8, Not Applicable Bolt Circle Diameter, Not Applicable Bolt Hole Diameter
