- Item
- UPS System
- VA Rating - UPS Systems
- 1.92 kVA
- UPS Type
- Line Interactive
- Power Rating
- 2200VA
- Mounting
- Rack
- Wattage
- 1.8 kW
- Input Voltage
- 120V AC
- Output Voltage
- 120V AC
- Backup Time (Half/Full Load)
- 15.8 min/5.4 min
- Outlet Type
- UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 8
- Ports
- RJ45 10/100Base-T, RJ45 Serial, Smart Slot, USB
- Display Type
- LCD
- NEMA Plug Configuration
- 5-20P
- Hz
- 50/60 Hz ( +/-3 Hz)
- Phase
- Single
- Transfer Time
- 4 to 8 msec
- NEMA Receptacle Configuration
- (2) 5-20R; (6) 5-15R
- Standards
- cULus, ENERGY STAR V2.0 (USA), RoHS
- Fax/Modem Line Protection
- No
- Automatic Volts Regulation
- Yes
- Input Current
- 16 A
- Includes
- Rack Mounting Brackets, Rack Mounting Support Rails, Smart UPS Signaling RS-232 Cable, USB Cables
- Housing Color
- Black
- Capacity - Batteries
- 1920 VA/1980 W
- Battery Type
- Lead Acid
- Housing Material
- Steel
- Product Certifications
- cULus || ENERGY STAR V2.0 (USA)
- Ambient Air Temperature For Storage
- -15-45°C
- Input Voltage Range
- 75 V AC - 154 V AC
- Presentation
- Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
- Ambient Air Temperature For Operation
- 0-40°C
- Free Slots
- 1
- Provided Equipment
- Rack Mounting brackets || Rack Mounting support rails || Smart UPS signalling RS-232 cable || USB cable
- Rated Power In Va
- 1920 VA
- Additional Specification
- cloud-enabled monitoring
- Alarm
- alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
- Battery Life
- 3-5 year(s)
- Hot Swappable
- Yes
- Number of Battery & Surge Outlets
- 8
- Package Contents
- Smart-UPS 2200VA LCD RM 2U 120V with SmartConnect , Rack mounting brackets, Rack mounting support rails, Smart UPS signalling RS-232 cable, USB cable
- Other Input Voltages
- 110 V || 125 V
- Control Panel
- LED status display with on line : on battery : replace battery and overload indicators, Multi-function LCD status and control console
- Input Frequency
- 50/60 Hz +/- 3 Hz auto-sensing
- Mounting Location
- front
- Usb Compatible
- Yes
- Battery Chemistry
- Valve Regulated Lead Acid
- Online Thermal Dissipation
- 215 Btu/h
- Kw Rating
- 1920 W
- Software Package
- SmartConnect software for remote power monitoring feature availability varies by terms of use
- Harmonic Distortion
- Less than 5%
- Number Of Cables
- 1
- Load Capacity
- 1920 VA/1980 W
- Relative Humidity
- 0-95 %
- Number Of Rack Unit
- 2U
- Storage Altitude
- 0-50000 ft
- Typical Battery Recharge Time
- 3 Hour
- Operating Altitude
- 0...10000 ft
- Efficiency At Full Load
- 75...154 V adjustable || 82...143 V
- Other Output Voltages
- 110 V || 125 V
- Form Factor
- Rack-mountable
- Surge Energy Rating
- 530 J
- Waveform Type
- Sine Wave
- Acoustic Level
- 55 dBA
- Communication Port Support
- SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use
- Plug Configuration
- 5-20P
- External Battery Compatible
- Not External Battery Pack Compatible
- Battery Life - Minimum
- 3 yr
- Battery Recharge Time
- 3 hr
- Replacement Battery Part Number
- RBC43
- Output Ports Included
- RS-232, USB
- Surge Suppression Rating
- 530 J
- Transfer Time - Maximum
- 10 msec
- Operating Temperature - Maximum
- 104 Degrees F
- Number of Outlets - UPS
- 8
- Includes Battery
- Battery Included
- Operating Temperature - Minimum
- 32 Degrees F
- Run Time - Full Load
- 6.07 min
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Frequency
- 50/60 Hz
- Receptacle Configuration
- 5-15R, 5-20R
- Power Rating - Apparent
- 2.2 kVA
- Transfer Time - Minimum
- 6 msec
- Audible Alarm Conditions
- Overload
- Manufacturer Warranty
- 3 yr
- Input Current - Maximum
- 16 A
- Power Rating - Real
- 1.92 kW
