- MFR #
- SMT3000RM2UC
- Zoro #
- G5105867
- UPC #
- 731304279549
- Country of Origin
- Philippines
- VA Rating - UPS Systems
- 2.88 kVA
- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 3000VA
- Mounting
- Rack
- Wattage
- 2.7 kW
- Input Voltage
- 120V AC
- Output Voltage
- 120V AC
- Backup Time (Half/Full Load)
- 11.7 min/3.4 min
- Outlet Type
- UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 8
- NEMA Receptacle Configuration
- (2) 5-20R; (6) 5-15R
- Input Current
- 24 A
- Phase
- Single
- Ports
- RJ45 10/100Base-T, RJ45 Serial,Smart Slot, USB
- Includes
- Documentation CD, Rack Mounting Hardware, Rack Mounting Support Rails, Smart UPS Signaling RS-232 Cable, USB Cables
- Standards
- cULus, ENERGY STAR V2.0 (USA), RoHS
- Transfer Time
- 4 to 8 msec
- Hz
- 50/60 Hz (+/-3 Hz)
- Automatic Volts Regulation
- Yes
- Display Type
- LCD
- Fax/Modem Line Protection
- No
- NEMA Plug Configuration
- L5-30P
- Battery Type
- Lead Acid
- Housing Color
- Black
- Capacity - Batteries
- 2880 VA/2700 W
- Housing Material
- Steel
- Mounting Location
- front
- Other Output Voltages
- 110 V || 125 V
- Battery Life
- 3-5 year(s)
- Operating Altitude
- 0...10000 ft
- Other Input Voltages
- 110 V || 125 V
- Product Certifications
- cULus || ENERGY STAR V2.0 (USA)
- Usb Compatible
- Yes
- Efficiency At Full Load
- 75...154 V adjustable || 82...144 V
- Rated Power In Va
- 2880 VA
- Software Package
- SmartConnect software for remote power monitoring feature availability varies by terms of use
- Acoustic Level
- 55 dBA
- Number Of Cables
- 1
- Presentation
- Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
- Communication Port Support
- SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use
- Harmonic Distortion
- Less than 5%
- Storage Altitude
- 0-50000 ft
- Kw Rating
- 2700 W
- Additional Specification
- cloud-enabled monitoring
- Alarm
- alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
- Ambient Air Temperature For Storage
- -15-45°C
- Relative Humidity
- 0-95 %
- Online Thermal Dissipation
- 348 Btu/h
- Free Slots
- 1
- Input Frequency
- 50/60 Hz +/- 3 Hz auto-sensing
- Control Panel
- LED status display with on line : on battery : replace battery and overload indicators, Multi-function LCD status and control console
- Provided Equipment
- Documentation CD || Installation guide || Rack mounting hardware || Rack Mounting support rails || Smart UPS signalling RS-232 cable || USB cable
- Ambient Air Temperature For Operation
- 0-40°C
- Number Of Rack Unit
- 2U
- Form Factor
- Rack-mountable
- Input Voltage Range
- 75 V AC - 154 V AC
- Hot Swappable
- Yes
- Typical Battery Recharge Time
- 3 Hour
- Battery Chemistry
- Valve Regulated Lead Acid
- Number of Battery & Surge Outlets
- 8
- Load Capacity
- 2880 VA/2700 W
- Surge Energy Rating
- 459 J
- Package Contents
- Smart-UPS 3000VA LCD RM 2U 120V with SmartConnect , Documentation CD, Installation guide, Rack mounting hardware, Rack mounting support rails, Smart UPS signalling RS-232 cable, USB cable
- Waveform Type
- Sine Wave
- Receptacle Configuration
- 5-15R, 5-20R
- Transfer Time - Minimum
- 6 msec
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Number of Outlets - UPS
- 8
- Run Time - Full Load
- 2.82 min
- Surge Suppression Rating
- 459 J
- Output Ports Included
- RS-232, USB
- External Battery Compatible
- Not External Battery Pack Compatible
- Power Rating - Real
- 2.7 kW
- Battery Life - Minimum
- 3 yr
- Input Current - Maximum
- 24 A
- Power Rating - Apparent
- 3 kVA
- Includes Battery
- Battery Included
- Manufacturer Warranty
- 3 yr
- Battery Recharge Time
- 3 hr
- Plug Configuration
- L5-30P
- Transfer Time - Maximum
- 10 msec
- Audible Alarm Conditions
- Overload
- Replacement Battery Part Number
- RBC43
- Operating Temperature - Maximum
- 104 Degrees F
- Operating Temperature - Minimum
- 32 Degrees F
- Frequency
- 50/60 Hz
- Run Time - Half Load
- 11.7 min
- Green Certification or Other Recognition
- ENERGY STAR(R) Certified
