- MFR #
- SUA5000R5TXFMR
- Zoro #
- G5365643
- UPC #
- -
- Country of Origin
- Philippines
- VA Rating - UPS Systems
- 5.0 kVA
- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 5000VA
- Mounting
- Rack
- Wattage
- 4 kW
- Input Voltage
- 208/240V AC
- Output Voltage
- 120/208/240V AC
- Backup Time (Half/Full Load)
- 26.7 min/9.4 min
- Outlet Type
- UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 12
- Input Current
- 24 A
- Standards
- CSA, RoHS
- Transfer Time
- 4 to 8 msec
- Automatic Volts Regulation
- Yes
- Display Type
- LED
- NEMA Receptacle Configuration
- (1) L6-30R; (12) 5-20R; (2) L6-20R
- Fax/Modem Line Protection
- No
- NEMA Plug Configuration
- L6-30P
- Hz
- 50/60 Hz (+/-5 Hz)
- Includes
- CD with Software, Rack Mounting Support Rails, Smart UPS Signaling RS-232 Cable
- Phase
- Single
- Battery Type
- Sealed Lead Acid (SLA)
- Capacity - Batteries
- 5000 VA/4000 W
- Housing Color
- Black
- Housing Material
- Steel
- Acoustic Level
- 53 dBA
- Usb Compatible
- No
- Ambient Air Temperature For Operation
- 0-40°C
- Number Of Cables
- 1
- Storage Altitude
- 0-50000 ft
- Harmonic Distortion
- less than 5 % at full load
- Online Thermal Dissipation
- 1708 Btu/h
- Mounting Location
- front
- Provided Equipment
- User Manual || Smart UPS signalling RS-232 cable || Rack Mounting support rails || CD with software
- Rated Power In Va
- 5000 VA
- Ambient Air Temperature For Storage
- -15-45°C
- Efficiency At Full Load
- 151...268 V adjustable || 157...255 V, 95 % full load)
- Input Frequency
- 50/60 Hz +/- 5 Hz auto-sensing
- Free Slots
- 0
- Control Panel
- LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators
- Kw Rating
- 4000 W
- Relative Humidity
- 0-95 %
- Operating Altitude
- 0...10000 ft
- Product Certifications
- CSA
- Alarm
- alarm when on battery : distinctive low battery alarm : configurable delays
- Number Of Rack Unit
- 7U
- Network Management
- SNMP Manageable
- Surge Energy Rating
- 1020 J
- Number of Battery & Surge Outlets
- 15
- Load Capacity
- 5000 VA/4000 W
- Package Contents
- Smart-UPS 5000VA Rack-mountable UPS , CD with software, Rack mounting support rails, Smart UPS signalling RS-232 cable, User manual
- Software Included
- PowerChute Management Software
- Form Factor
- Rack-mountable
- Network (RJ-45)
- Yes
- Emergency Power OFF
- Optional
- Battery Chemistry
- Valve Regulated Lead Acid
- Waveform Type
- Sine Wave
- Total Number of Expansion Slots
- 1
- Dataline Protection
- RJ-45
- Battery Characteristics
- Spill-proof, Maintenance-free
- Typical Battery Recharge Time
- 3 Hour
- Audible Alarm Conditions
- Low Battery
- Run Time - Full Load
- 9.35 min
- Power Rating - Apparent
- 5 kVA
- Output Ports Included
- RS-232
- Operating Temperature - Minimum
- 32 Degrees F
- Manufacturer Warranty
- 2 yr
- Includes Battery
- Battery Included
- Surge Suppression Rating
- 1,020 J
- External Battery Compatible
- Not External Battery Pack Compatible
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Power Rating - Real
- 4 kW
- Number of Outlets - UPS
- 12
- Transfer Time - Minimum
- 2 msec
- Plug Configuration
- L6-30P
- Receptacle Configuration
- 5-20R, L6-20R, L6-30R
- Frequency
- 50/60 Hz
- Replacement Battery Part Number
- RBC55
- Battery Recharge Time
- 3 hr
- Input Current - Maximum
- 24 A
- Operating Temperature - Maximum
- 104 Degrees F
- Transfer Time - Maximum
- 4 msec
- Run Time - Half Load
- 26.7 min
