- MFR #
- SUA5000RMT5U
- Zoro #
- G5120549
- UPC #
- 731304255338
- Country of Origin
- India
- Item
- UPS System
- VA Rating - UPS Systems
- 5.0 kVA
- UPS Type
- Line Interactive
- Power Rating
- 5000VA
- Mounting
- Rack
- Wattage
- 4 kW
- Input Voltage
- 208/240V AC
- Output Voltage
- 120/208/240V AC
- Backup Time (Half/Full Load)
- 26.7 min/9.4 min
- Outlet Type
- UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 4
- NEMA Receptacle Configuration
- (2) L6-20R; (2) L6-30R
- Hz
- 50/60 Hz (+/-5 Hz)
- Phase
- Single
- Display Type
- LED
- Includes
- Rack Mounting Support Rails, Smart Ups Signalling RS-232 Cable
- Standards
- CSA, RoHS
- Fax/Modem Line Protection
- No
- Input Current
- 24 A
- Automatic Volts Regulation
- Yes
- Transfer Time
- 4 to 8 msec
- Ports
- EPO, RJ45 Serial, Smart Slot, USB
- NEMA Plug Configuration
- L6-30P
- Housing Color
- Black
- Battery Type
- Sealed Lead Acid (SLA)
- Capacity - Batteries
- 5000 VA/4000 W
- Housing Material
- Steel
- Free Slots
- 0
- Online Thermal Dissipation
- 344 Btu/h
- Acoustic Level
- 53 dBA
- Usb Compatible
- No
- Rated Power In Va
- 5000 VA
- Battery Life
- 3-5 year(s)
- Operating Altitude
- 0...10000 ft
- Provided Equipment
- CD with software || Rack Mounting support rails || Smart UPS signalling RS-232 cable || User Manual || Web/SNMP Management Card
- Alarm
- alarm when on battery : distinctive low battery alarm : configurable delays
- Control Panel
- LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators
- Efficiency At Full Load
- 131...268 V adjustable || 141...255 V
- Ambient Air Temperature For Storage
- -5-55°C
- Product Certifications
- CSA
- Number Of Cables
- 1
- Relative Humidity
- 0-95 %
- Kw Rating
- 4000 W
- Storage Altitude
- 0-50000 ft
- Number Of Rack Unit
- 5U
- Mounting Location
- front
- Harmonic Distortion
- less than 5 % at full load
- Input Frequency
- 50/60 Hz +/- 5 Hz manual switch
- Presentation
- Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
- Ambient Air Temperature For Operation
- 0-45°C
- Waveform Type
- Sine Wave
- Battery Characteristics
- Spill-proof, Maintenance-free
- Typical Battery Recharge Time
- 3 Hour
- Hot Swappable
- Yes
- Package Contents
- Smart-UPS 5000VA Tower/Rack-mountable UPS , CD with software, Rack mounting support rails, Smart UPS signalling RS-232 cable, User manual, Web/SNMP management card
- Load Capacity
- 5000 VA/4000 W
- Network Management
- SNMP Manageable
- Emergency Power OFF
- Optional
- Number of Battery & Surge Outlets
- 4
- Form Factor
- Rack-mountable
- Surge Energy Rating
- 480 J
- Battery Chemistry
- Valve Regulated Lead Acid
- Transfer Time - Maximum
- 4 msec
- Manufacturer Warranty
- 2 yr
- Number of Outlets - UPS
- 4
- Output Ports Included
- RS-232, SNMP
- Operating Temperature - Minimum
- 32 Degrees F
- Transfer Time - Minimum
- 2 msec
- Frequency
- 50/60 Hz
- Audible Alarm Conditions
- Low Battery
- Power Rating - Apparent
- 5 kVA
- Input Current - Maximum
- 24 A
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Includes Battery
- Battery Included
- Surge Suppression Rating
- 480 J
- Plug Configuration
- L6-30P
- External Battery Compatible
- Not External Battery Pack Compatible
- Battery Life - Minimum
- 3 yr
- Battery Recharge Time
- 3 hr
- Operating Temperature - Maximum
- 113 Degrees F
- Power Rating - Real
- 4 kW
- Receptacle Configuration
- L6-20R, L6-30R
- Replacement Battery Part Number
- RBC55
- Run Time - Full Load
- 9.35 min
- Run Time - Half Load
- 26.7 min
