- Item
- UPS System
- UPS Type
- Standby
- Power Rating
- 600VA
- Mounting
- Floor/Wall
- Wattage
- 330 W
- Input Voltage
- 120V AC
- Output Voltage
- 120V AC
- Backup Time (Half/Full Load)
- 11.5 min/2.5 min
- Outlet Type
- Surge
- Medical Grade
- No
- Number of Outlets
- 7
- Standards
- California (CEC) Battery Charger, cTUVus, NOM, RoHS
- NEMA Plug Configuration
- 5-15P
- Ports
- RJ45 Serial, Smart Slot, USB
- Hz
- 50/60 Hz ( +/-3 Hz)
- Automatic Volts Regulation
- No
- Fax/Modem Line Protection
- Yes
- Phase
- Single
- Input Current
- 9 A
- Transfer Time
- 6 to 10 msec
- VA Rating - UPS Systems
- 600.0 VA
- Display Type
- LED
- NEMA Receptacle Configuration
- No Configuration
- Battery Type
- Lead Acid
- Housing Material
- Steel
- Control Panel
- LED status display with on line : on battery : replace battery and overload indicators
- Number of Battery & Surge Outlets
- 7
- Relative Humidity
- 0-90 %
- Sound Emission (A-Weighted)
- 35 dB(A)
- Ambient Air Temperature For Operation
- 0-40°C
- Battery Life
- 3-5 year(s)
- Input Voltage Range
- 92 V AC - 139 V AC
- Application/Usage
- Television, Wi-Fi Router, Security System, Gaming Console, Modem, Cable Box/DVR, Wireless Router, Network, IOT Device, Electronic, Computer
- Form Factor
- Tower
- Status Indicators
- LED Status Display: On Line, On Battery, Replace Battery , Overload
- Acoustic Level
- 35 dBA
- Rated Power In Va
- 600 VA
- Provided Equipment
- User Manual
- Surge Energy Rating
- 490 J
- Product Certifications
- California (CEC) Battery Charger || cTUVus || NOM
- Maximum Storage Elevation
- 49212.60 ft
- Alarm
- alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
- Battery Energy
- 237.6 kJ
- Usb Compatible
- No
- Ambient Air Temperature For Storage
- -15-45°C
- Input Frequency
- 50/60 Hz +/- 3 Hz auto-sensing
- Efficiency At Full Load
- 92...139 V
- Kw Rating
- 330 W
- Online Thermal Dissipation
- 16 Btu/h
- Output Frequency
- 60 Hz
- Replaceable Battery
- Yes
- Battery Characteristics
- Maintenance-free, Sealed, Leak-proof
- Operating Altitude
- 0...10000 ft
- Hot Swappable
- Yes
- Maximum Operating Elevation
- 9842.52 ft
- Waveform Type
- Stepped Approximated Sine Wave
- Storage Altitude
- 0-50000 ft
- Maximum Operating Temperature
- 104°F (40°C)
- Load Capacity
- 600 VA/330 W
- Typical Battery Recharge Time
- 10 Hour
- Battery Chemistry
- Valve Regulated Lead Acid
- Thermal Dissipation
- 4.69 W
- Storage Temperature
- 5°F (-15°C) - 113°F (45°C)
- Package Contents
- Back-UPS 600VA Tower UPS , User manual
- Includes Battery
- Battery Included
- Surge Suppression Rating
- 490 J
- Transfer Time - Maximum
- 10 msec
- Battery Recharge Time
- 10 hr
- Run Time - Full Load
- 4.73 min
- Audible Alarm Conditions
- Overload
- Operating Temperature - Maximum
- 104 Degrees F
- Plug Configuration
- 5-15P
- Operating Temperature - Minimum
- 32 Degrees F
- Input Current - Maximum
- 9 A
- Number of Outlets - Surge Only
- 2
- Frequency
- 50/60 Hz
- Battery Life - Minimum
- 3 yr
- Receptacle Configuration
- 5-15R
- Power Rating - Apparent
- 600 VA
- Manufacturer Warranty
- 3 yr
- External Battery Compatible
- Not External Battery Pack Compatible
- Data Line Protection
- Includes Data Line Surge Protection
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Transfer Time - Minimum
- 6 msec
- Number of Outlets - UPS
- 5
- Replacement Battery Part Number
- APCRBC154
- Output Ports Included
- USB
- Power Rating - Real
- 330 W
- Green Certification or Other Recognition
- ENERGY STAR(R) Certified
- Run Time - Half Load
- 11.5 min
