- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 900VA
- Mounting
- Tower
- Wattage
- 475 W
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V AC
- Backup Time (Half/Full Load)
- 10 min/3 min
- Outlet Type
- (4) Surge; (4) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 8
- Display Type
- LCD
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Automatic Volts Regulation
- Yes
- VA Rating - UPS Systems
- 900.0 VA
- Footnotes
- 4
- Phase
- Single
- Special Features
- Automatic Voltage Regulation Conditions Power Through Brownouts, LCD Display Indicates Input Voltage, Battery Capacity And A Variety Of Operating Conditions, Poweralert Software
- Includes
- UPS System
- Hz
- 60 Hz
- Ports
- USB (HID enabled)
- Input Current
- 12 A
- NEMA Plug Configuration
- 5-15P
- Fax/Modem Line Protection
- No
- Transfer Time
- 2 to 4 msec
- Standards
- CSA, FCC Part 15 Class B, NOM, RoHS, UL1778
- NEMA Receptacle Configuration
- (8) 5-15R
- Voltage
- 120
- Housing Color
- Black
- Operating Temp. Range
- 122°F (50°C)
- Capacity - Batteries
- 900 VA/475 W
- Input Connection
- 6 ft Cord with NEMA 5-15P Plug
- Battery Type
- VRLA
- Housing Material
- ABS
- Communications Cable
- User supplies USB cable
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- Communications Interface
- USB (HID enabled)
- Audible Alarm
- Audible alarm indicates power-failure and low-battery status; alarm can be disabled using PowerAlert software
- Output Volt Amp Capacity (VA)
- 900
- Battery Access
- Battery access door
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert
- Hot-Swap PDU options
- PDUB15 (2U / 8 5-15R outlets)
- Front Panel LCD Display
- Backlighted LCD screen indicates input voltage, 5-bar battery charge level, overload, AVR, on battery and replace battery status; LCD screen rotates for rack/tower viewing
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- High Voltage Transfer to Battery Power (Setpoint)
- 139
- Battery Replacement Description
- Hot-swappable, user replaceable batteries
- Relative Humidity
- 0 to 95%, non-condensing
- Undervoltage Correction
- Input voltages between 89 and 104 are boosted by 14%
- UPS Certifications
- Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- Voltage Regulation Description
- Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
- UPS AC Suppression Joule Rating
- 870
- Rated input current (Maximum Load)
- 12A
- Recommended Electrical Service
- 15A 120V
- Input Phase
- Single-Phase
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Battery Recharge Rate (Included Batteries)
- Less than 16 hours from 10% to 90%
- Individually Controllable Load Banks
- No
- Nominal Input Voltage(s) Supported
- 120V AC
- Output AC Waveform (Battery Mode)
- PWM sine wave
- Alarm Cancel Operation
- Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status
- Switches
- 2 Switches control off/on power status and alarm-cancel/self-test operation; dimmer switch controls LCD brightness
- Expandable Runtime
- No
- Half Load Runtime (min.)
- 10 min. (240w)
- Full Load Runtime (min.)
- 3 min. (475w)
- AC Mode BTU / Hr. (Full Load)
- 61
- Internal UPS Replacement Battery Cartridge
- RBC51
- UPS AC Suppression Response Time
- Instantaneous
- LED Indicators
- Front panel LCD display
- AC Mode Efficiency Rating (100% Load)
- 0.97
- Installation Form Factors Supported with Included Accessories
- Tower
- Network UPS Tools Compatibility
- NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
- Output Watt Capacity (Watts)
- 475
- Battery Mode BTU / Hr. (Full Load)
- 485
- Primary Form Factor
- Tower
- DC System Voltage (VDC)
- 12
- EMI / RFI AC Noise Suppression
- Yes
- Low Voltage Transfer to Battery Power (Setpoint)
- 89
- USB
- Yes
- Load Capacity
- 900 VA/475 W
- Software Included
- PowerAlert software
- Surge Energy Rating
- 870 J
- Battery Life
- 6 Year
- Alarm
- AC Input Failure
- Additional Information
Low voltage transfer to battery power: Switches to battery power as line voltage decreases to 89V or less, switches back to AC mode as line voltage increases to 94V or higher, High voltage transfer to battery power: Switches to battery mode as line voltage increases to 139V or higher, switches back to AC mode as line voltage decreases to 135V or lower, Network monitoring port: Single built-in USB port supports on battery, low battery and power restored messaging. Interface supports timed inverter shutoff after unattended shutdown. Compatible with Tripp Lite's PowerAlert and Watchdog service software, Compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment ideal for unattended kiosk applications, Switches: Includes 2 front panel switches - one main on/off power switch and one dual function "alarm cancel" / "self test" button, Entry-level PCs, networked workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems. Ideal for sensitive electronic applications in areas where brownout conditions are common
- Package Contents
- OmniSmart OMNI900LCD 900 VA Tower UPS, Manual with Warranty Information
- Hot Swappable
- Yes
- Waveform Type
- Pulse-width Modulated Sine Wave
- Status Indicators
- Front panel LCD screen with blue backlight offers: Continuous input line voltage data, UPS status information on line power status, Battery power status, Battery charge level, Voltage regulation operation
- Maximum Operating Temperature
- 122°F (50°C)
- Form Factor
- Tower
- Typical Battery Recharge Time
- 20 Hour
- Package Includes
- OMNI900LCD UPS System;Instruction manual
- Output Capacity (Watts)
- 475
- High Availability UPS Features
- Automatic Voltage Regulation (AVR); Hot swappable batteries; Surge/noise protection
- UPS Applications
- Home/Office Desktop; Audio/Video; Retail/Point of Sale; Hospitality
- Product Compliance
- FCC Part 15 Class B (USA)
- Output Capacity (VA)
- 900
- Product Certifications
- CSA (Canada); NOM (Mexico); UL 1778
- Transfer Time - Minimum
- 3 msec
- Audible Alarm Conditions
- Low Battery, Power Outage
- Number of Outlets - UPS
- 4
- Input Current - Maximum
- 12 A
- Number of Outlets - Surge Only
- 4
- Plug Configuration
- 5-15P
- Output Ports Included
- USB
- Operating Temperature - Maximum
- 104 Degrees F
- Run Time - Full Load
- 3 min
- Data Line Protection
- No Data Line Surge Protection
- Transfer Time - Maximum
- 4 msec
- Manufacturer Warranty
- 3 yr Limited
- Frequency
- 60 Hz
- Battery Recharge Time
- 16 hr
- Power Rating - Real
- 475 W
- Replacement Battery Part Number
- RBC51
- Receptacle Configuration
- 5-15R
- Operating Temperature - Minimum
- 32 Degrees F
- Power Rating - Apparent
- 900 VA
- Includes Battery
- Battery Included
- Visible Indicator Light Conditions
- Overload, Replace Battery
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Battery Chemistry
- Valve Regulated Lead Acid
- External Battery Compatible
- Not External Battery Pack Compatible
