- VA Rating - UPS Systems
- 8.0 kVA
- Item
- UPS System
- UPS Type
- Online/Double Conversion
- Power Rating
- 8000VA
- Mounting
- Rack/Tower
- Wattage
- 8 kW
- Input Voltage
- 208/240V AC
- Output Voltage
- 208/240V AC
- Backup Time (Half/Full Load)
- 14.4 min/5.2 min
- Outlet Type
- Hardwired
- Medical Grade
- No
- Number of Outlets
- 7
- Display Type
- No Display
- Hz
- 40 to 70 Hz
- Transfer Time
- 0 msec
- Automatic Volts Regulation
- No
- Phase
- Single
- Input Current
- 47 A
- Fax/Modem Line Protection
- No
- Standards
- ENERGY STAR V2.0 (USA), FCC Part 15 Class A, NOM, RoHS, UL 1778
- NEMA Receptacle Configuration
- (4) L6-20R; (2) L6-30R
- Includes
- Rack Mounting Brackets, Rack Mounting Hardware, Rack Mounting Support Rails, Temperature Probe
- Housing Color
- Black
- Capacity - Batteries
- 8000 VA/8000 W
- Battery Type
- Lead Acid
- Housing Material
- Steel
- Harmonic Distortion
- Less than 2%
- Ip Degree Of Protection
- IP20
- Online Thermal Dissipation
- 1712 Btu/h
- Product Certifications
- ENERGY STAR V2.0 (USA) || FCC part 15 class A || NOM || UL 1778
- Additional Specification
- high density
- Bypass Type
- Internal Bypass (Automatic and Manual)
- Ambient Air Temperature For Storage
- -15-45°C
- Mounting Location
- front
- Number Of Rack Unit
- 6U
- Crest Factor
- 0.125694444444444
- Acoustic Level
- 55 dBA
- Battery Life
- 3-5 year(s)
- Usb Compatible
- Yes
- Battery Voltage
- +/-192 V (split battery referenced to neutral)
- Kw Rating
- 8000 W
- Alarm
- audible and visible alarms : prioritized by severity
- Rated Power In Va
- 8000 VA
- Storage Altitude
- 0-50000 ft
- Other Input Voltages
- 240 V
- Free Slots
- 1
- Relative Humidity
- 0-95 % non-condensing
- Other Output Voltages
- 240 V
- Operating Altitude
- 0...10000 ft
- Ambient Air Temperature For Operation
- 0-40°C
- Input Frequency
- 40 - 70 Hz auto-sensing
- Efficiency At Full Load
- 100...275 V adjustable (half load)
- Provided Equipment
- CD with software || Documentation CD || Installation guide || Rack mounting hardware || Rack Mounting brackets || Rack Mounting support rails || Temperature Probe || USB cable || Warranty card || Web/SNMP Management Card
- Surge Energy Rating
- 480 J
- Number of Battery & Surge Outlets
- 6
- Form Factor
- Rack-mountable
- Waveform Type
- Sine Wave
- Battery Chemistry
- Valve Regulated Lead Acid
- Load Capacity
- 8000 VA/8000 W
- Typical Battery Recharge Time
- 1.50 Hour
- Package Contents
- Smart-UPS SRT 8000VA RM 208V , CD with software, Documentation CD, Installation guide, Rack mounting brackets, Rack mounting hardware, Rack mounting support rails, Temperature probe, USB cable, Warranty card, Web/SNMP management card
- Battery Life - Minimum
- 3 yr
- Operating Temperature - Maximum
- 104 Degrees F
- Power Rating - Apparent
- 8 kVA
- External Battery Compatible
- External Battery Pack Compatible
- Receptacle Configuration
- Hardwired, L6-20R, L6-30R
- Manufacturer Warranty
- 3 yr
- Power Rating - Real
- 8 kW
- Operating Temperature - Minimum
- 32 Degrees F
- Surge Suppression Rating
- 480 J
- Output Ports Included
- SNMP, USB
- Input Current - Maximum
- 47 A
- External Battery Pack Part Number
- SRT192RMBP2
- Run Time - Full Load
- 5.17 min
- Plug Configuration
- Hardwired
- Frequency
- 40 to 70 Hz
- Includes Battery
- Battery Included
- Battery Recharge Time
- 1.5 hr
- Transfer Time - Minimum
- 0 msec
- Replacement Battery Part Number
- APCRBC140, SRT192BP2US, SRT192RMBPUS
- Number of Outlets - UPS
- 7
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Run Time - Half Load
- 14.4 min
- Green Certification or Other Recognition
- ENERGY STAR(R) Certified
