Shop APOLLO VALVES

3 in Ball Valve, Brass, FNPT, Inline

  • Mfr # 94A10001

  • Zoro # G1237844

product price:  $262.99
/ea
Free Shipping & Returns

Key Features

Ball Material
Chrome-Plated Brass
Body Style
Inline
Ball Port Style
Full Port
Valve Ways
2-Way
Valve Structure
Two-Piece
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
94A10001
Zoro #
G1237844
UPC #
670750823558
Country of Origin
China

Dimensions

Pipe Size
3 in
Overall Length
6.04 in
Handle Length
8.7 in
Handle Height
4.97 in
Connection Size - Side 1
3 in
Connection Size - Side 2
3 in
Nominal Valve Size
3 in
Wire Rope Length
6.04 in

Details

Ball Material
Chrome-Plated Brass
Body Style
Inline
Ball Port Style
Full Port
Valve Ways
2-Way
Valve Structure
Two-Piece
For Media
Combustible Gases
Connection Type
FNPT x FNPT
Item
Ball Valve
Stem Type
Blowout Resistant
Handle Material
PVC, Steel
Features
General Purpose
Temp. Range
0 Degrees to 400 Degrees F
Max. Pressure
400 PSI CWP
Handle Type
Lever
Body Material
Brass
Compliance
MSS SP-110
Seat Material
PTFE
Ball Valve Product Group
Manual
Standards
CSA, FM
Stem Material
Brass
Seal Material
EPDM
Type
Two Piece
Valve Design
2-Piece
Connection Gender - Side 2
Female
Maximum Pressure - Steam
Not Rated
Connection Type - Side 1
NPT
Connection Type - Side 2
NPT
Operating Temperature - Maximum
400 Degrees F
Coefficient of Volume (Cv)
0
3-A Standard Compliance
Not Rated
Cleaned and Bagged
Not Cleaned and Bagged
Operating Temperature - Minimum
0 Degrees F
Handle - Locking
Non-Locking
Color - Valve Handle
Yellow
Maximum Pressure - Combustible Gas
Not Rated
Connection Gender - Side 1
Female
Meets UL Flammable Gas and Liquid Standards
UL 125, UL 1477, UL 842
Valve Series
94A
Valve Body Style
Straight
Valve Construction
Two-Piece
Manufacturer Warranty
2 yr
Maximum Pressure - Operating
400 psi

Description

The APOLLO VALVES 94A10001 is a 3 in manual ball valve with a two-piece inline brass body and full port design. It has female NPT connections on both ends (FNPT x FNPT) and is intended for general purpose service with combustible gases. The valve uses a chrome plated brass ball, brass stem, PTFE seats, and EPDM seals, with a lever handle made from PVC and steel.

Key Features:

  • 3 in valve size: Matches 3 in pipe size with 3 in female NPT connections on both sides.
  • Full port ball: Allows full flow through the valve opening.
  • Two-way, inline design: Used for on/off flow control in a straight pipe run.
  • Brass body and stem: Valve body and stem are made of brass.
  • Chrome plated brass ball: Ball material is brass with chrome plating.
  • PTFE seats and EPDM seals: Internal sealing components use PTFE seats and EPDM seal material.
  • Manual lever handle: Non-locking yellow lever handle with PVC and steel construction.
  • Pressure and temperature: Rated to 400 PSI CWP with a temperature range of 0 to 400 degrees F.
  • Blowout resistant stem: Stem is designed as blowout resistant.
  • Standards: MSS SP-110; UL 125, UL 1477, UL 842; CSA; FM.

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
