3/8" NPT Lead Free Bronze Dual Check Valve

Mfr # 4NLF3A22A
Zoro # G5151605

70.85

Key Features

Pipe Size

3/8"

Connection Type

FNPT x FNPT

Connection

FNPT x FNPT

Body Material

Lead Free Bronze

Min. Temp. - Valves

33 Degrees F

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: 4NLF3A22A
Zoro #: G5151605
UPC #: 670750509858
Country of Origin: China

Dimensions

Pipe Size: 3/8"
Length: 3.32"
Pipe or Tube Size - Check Valves: 3/8"
Width: 1.88"
Overall Height: 1.88 in
Overall Length: 3.32 in
Pipe or Tube Size: 3/8 in
Connection Size - Side 2: 3/8 in
Connection Size - Side 1: 3/8 in
Nominal Valve Size: 3/8 in
Overall Width: 1.88 in
Wire Rope Length: 3.32 in

Details

Connection Type: FNPT x FNPT
Connection: FNPT x FNPT
Body Material: Lead Free Bronze
Min. Temp. - Valves: 33 Degrees F
Application - Valves: General Purpose
Flow Design: Dual
Item: Dual Check Valve
Material of Construction: Lead Free Bronze
Standards: ASSE, CSA, ISO
Compliance: NSF 372
Max. Water Pressure: 175 psi
Spring Material - Check Valves: Stainless Steel
Connection Type - Check Valves: FNPT x FNPT
Max. Steam Pressure - Valves: 125 psi WSP
Max. Pressure: 175 psi
Seat Material - Check Valves: Buna-N
Seal Material - Check Valves: EPDM
Item - Check Valves: Check Valve
Max. Water Pressure - Valves: 175 psi
Mechanism and Body Design: Inline
Body Material - Valves: Bronze
Mounting Orientation - Check Valves: Horizontal
Max. Temp. - Valves: 180 Degrees F
Cracking Pressure: 2 psi
Spring Material: Stainless Steel
Seat Material: Buna-N, EPDM
Flow: 12.5 gpm
Seal Material: EPDM
Mounting Orientation: Horizontal
Check Mechanism Material: Acetal
Connection Type - Side 2: NPT
For Media: Water
Includes Freeze Protection: No Freeze Protection
Field Testable: Not Field Testable
Includes Atmospheric Vent: No Atmospheric Vent
Operating Temperature - Minimum: 33 Degrees F
Hazard Protection Level: Low Hazard
Connection Gender - Side 2: Female
Operating Temperature - Maximum: 180 Degrees F
Maximum Pressure - Operating: 175 psi
Connection Type - Side 1: NPT
Connection Gender - Side 1: Female
Valve Series: 4N

Description

Dual Check Valve, Size 3/8 In., Connection NPT, Body Material Bronze, Max. Temp. 180 Degrees F, Max. Pressure 175 psi, Length 3 5/16 in, Standards ASSE, CSA, ISO, Compliance NSF 372

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
