Apollo Valves Water Pressure Reducing Valve, 1 In. 36LF40501 - main

Water Pressure Reducing Valve, 1 In.

  • Mfr # 36LF40501

  • Zoro # G5286531

product price: $178.99
/ea
Free Shipping & Returns

Key Features

Pipe Size
1"
Connection Type
Double Union NPT
Body Material
Lead Free Bronze
Max. Pressure
300 psig
Max. Temp.
180 Degrees F
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
36LF40501
Zoro #
G5286531
UPC #
670750930584
Country of Origin
United States

Dimensions

Pipe Size
1"
Length
6 3/8 in
Height
6 8/9 in
Overall Height
5 5/8 in
Overall Width
6 3/8 in
Outlet Connection Size
1 in
Inlet Connection Size
1 in

Details

Connection Type
Double Union NPT
Body Material
Lead Free Bronze
Max. Pressure
300 psig
Max. Temp.
180 Degrees F
Item
Water Pressure Reducing Valve
Valve Type
Standard
Strainer
No
Material
Lead Free Bronze
Standards
ASSE 1003, CSA B356, NSF 372,ARRA
Pressure Adjustment Range
5 to 75 psig
Application
Residential and Commercial
Preset Pressure Settings
50 psi
Material of Construction
Lead Free Bronze
Connection
Double Union FNPT
Factory Set Pressure
50 psi
Disc Material
EPDM
Seat Material
EPDM
NSF Certifications for Food and Drinking Water
NSF 372
Outlet Connection Type
NPT
Coating/Lining
NSF Listed Fusion Bonded Epoxy Lining and Coating
Inlet Connection Type
NPT
Pilot Adjustment - Minimum
25 psig
Operating Pressure - Minimum
25 psi
Pilot Adjustment - Maximum
75 psig
Flow Rate - Continuous Maximum
46 gpm
Includes Strainer
Strainer Included
Operating Pressure - Maximum
300 psi
Fluid Temperature - Maximum
180 Degrees F
For Media
Water
Bonnet Material
Bronze

Description

Valve, Pressure Reducing, Material of Construction Lead Free Bronze, Inlet/Outlet 1 In., Double Union NPT Connection, Max. Working Pressure (PSI) 300, Adjustable Range 25-75 psi, Pressure Setting 50 psi, Max. Temp. (F) 180, Height (In.) 6-8/9, Length (In.) 6-19/50, Certification CA AB1953, VT ACT 193, Standards ASSE 1003/CSA B356, Compliance ARRA

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
