Apollo Valves Water Pressure Reducing Valve, 2 In. 36LF50801 - main

Water Pressure Reducing Valve, 2 In.

  • Mfr # 36LF50801

  • Zoro # G5274656

product price: $599.99
/ea
Free Shipping & Returns

Key Features

Pipe Size
2"
Connection Type
Double Union Solder
Body Material
Lead Free Bronze
Max. Pressure
300 psig
Max. Temp.
180 Degrees F
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
36LF50801
Zoro #
G5274656
UPC #
670750651489
Country of Origin
United States

Dimensions

Pipe Size
2"
Height
11 1/2 in
Length
10 1/2 in
Overall Height
5 5/8 in
Overall Width
10 1/2 in
Inlet Connection Size
2 in
Outlet Connection Size
2 in

Details

Connection Type
Double Union Solder
Body Material
Lead Free Bronze
Max. Pressure
300 psig
Max. Temp.
180 Degrees F
Item
Water Pressure Reducing Valve
Valve Type
Standard
Application
Residential and Commercial
Strainer
No
Preset Pressure Settings
50 psi
Material
Lead Free Bronze
Pressure Adjustment Range
5 to 75 psig
Standards
ASSE 1003, CSA B356, NSF 372,ARRA
Material of Construction
Lead Free Bronze
Connection
Double Union Solder
Seat Material
EPDM
Factory Set Pressure
50 psi
Disc Material
EPDM
Coating/Lining
NSF Listed Fusion Bonded Epoxy Lining and Coating
Inlet Connection Type
Solder
Pilot Adjustment - Maximum
75 psig
Outlet Connection Type
Solder
Includes Strainer
Strainer Included
Fluid Temperature - Maximum
180 Degrees F
Flow Rate - Continuous Maximum
127 gpm
NSF Certifications for Food and Drinking Water
NSF 372
For Media
Water
Bonnet Material
Bronze
Pilot Adjustment - Minimum
25 psig
Operating Pressure - Minimum
25 psi
Operating Pressure - Maximum
300 psi

Description

Valve, Pressure Reducing, Material of Construction Lead Free Bronze, Inlet/Outlet 2 In., Double Union Solder Connection, Max. Working Pressure (PSI) 300, Adjustable Range 25-75 psi, Pressure Setting 50 psi, Max. Temp. (F) 180, Height (In.) 11-1/2, Length (In.) 10-1/2, Certification CA AB1953, VT ACT 193, Standards ASSE 1003/CSA B356, Compliance ARRA

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
