Shop APPLETON ELECTRIC

Plug

  • Mfr # ACP6044BC

  • Zoro # G422639472

product price:
$
450.99
/ea
Free Shipping & Returns

Key Features

For Minimum Cable Diameter
0.5 in
Wire Rope Length
7.8 in
Horsepower Rating
50 hp
Voltage Rating
600V AC
Current Rating
60 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ACP6044BC
Zoro #
G422639472
UPC #
781381440233
Country of Origin
Mexico

Dimensions

For Minimum Cable Diameter
0.5 in
Wire Rope Length
7.8 in
Outside Diameter
3.63 in
Minimum Wire Size
6 AWG
Maximum Wire Size
2 AWG
For Maximum Cable Diameter
1.375 in
Overall Length
7.8 in
Length
7.8 in

Details

Horsepower Rating
50 hp
Voltage Rating
600V AC
Current Rating
60 A
Housing Color
Gray
Wire Connection Type
Wire Leads
Polarized
Yes
Housing Material
Aluminum
Series
Powertite(TM)
Minimum Operating Temperature
-13 Degrees F
Number of Poles
4
Power Indicating Light
No
Reverse Service
No
Resistance Properties
Weather Resistant
Grounding Style
Style 1
Features
These Units Offer Rough Usage Construction, a Wide Range of Amperage and Feature Widely Spaced Contacts Recessed within an Internal Arc Snuffing Chamber, Insulating Blocks and a Durable Neoprene Sealing Bushing
Item
Pin and Sleeve Plug
Grounding
Grounded
Insulation Material
Glass Filled Polyester
Maximum Operating Temperature
104 Degrees F
IP Rating
Not Rated
For Environment
Hazardous Location
Number of Wires
4
Housing Material Finish
Epoxy Powder Coated
Standards
CSA, cULus, UL
Phase
Three
NEMA Enclosure Rating
4X

Description

Pin and Sleeve Plug, Current Rating 60 A, Hazardous Location Specification Not Applicable, Horsepower Rating 50 hp, Housing Color Gray, IP Rating Not Rated, Number of Poles 4, Number of Wires 4, Phase Three, Voltage Rating 600V AC, Wire Connection Type Wire Leads, For Maximum Cable Diameter 1.375 in, For Minimum Cable Diameter 0.5 in, Grounding Grounded, Grounding Style Style 1, Housing Material Aluminum, Maximum Wire Size 2 AWG, Minimum Wire Size 6 AWG, NEMA Enclosure Rating 4X
