  9. Pressure Gauge, 0 to 60 psi
Ashcroft Pressure Gauge, 0 to 60 psi 351130FD25SXCYLM60PSID - main

Pressure Gauge, 0 to 60 psi

  • Mfr # 351130FD25SXCYLM60PSID

  • Zoro # G0017577

product price: $177.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-2.00%
Process Connection Type
NPT
Process Connection Size
1/4 in
Series
1130
Process Connection Gender
Female
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
351130FD25SXCYLM60PSID
Zoro #
G0017577
UPC #
783029143049
Country of Origin
India

Dimensions

Process Connection Size
1/4 in
Nominal Dial Size
3 1/2 in
Gauge Nominal Dial Size
3 1/2 in
Differential Gauge Connection Size
1/4 in
Manufacturers Warranty Length
5 yr
Case Diameter
4 1/4 in
Bolt Circle Diameter
3.86 in
Case Depth
1.75 in
Manufacturer Warranty Length
5 yr

Details

Item
Differential Pressure Gauge
Accuracy
+/-2.00%
Process Connection Type
NPT
Series
1130
Process Connection Gender
Female
Application
Filtration Monitoring, Flow Measurement, Pressure Detection
Process Connection Location
In-Line
Housing Material
Aluminum
Pressure Range
0 to 60 psid
Sensor Type
Diaphragm
Standards
Class 1, Groups B, C, D, Class 2 Groups E, F, G, Class 3, NEMA 7, 9 and IP 66
Differential Pressure Gauge Type
Differential Pressure Gauge
Scale Type
Pressure
Differential Pressure Range Units
psi
Differential Pressure Range
0 to 60 psi
Differential Pressure Range Value
0 to 60
Basic Gauge Wetted Parts
PTFE / Buna-N / Viton or EPDM
Gauge Accuracy
+/-2%
Diaphragm Material
Buna-N
Rated Total Pressure
6,000 psi
Gauge Primary Range Smallest Graduation
5
Includes
Instructions
Piston Material
PTFE
Differential Gauge Connection Type
FNPT
Gauge Operating Temp. Range
0 Degrees to 170 Degrees F
Dial Material
Stainless steel
Gauge Connection Location
Inline
Basic Gauge Case Material
Metal
Body Material
Aluminum
Seal Material
Buna-N, Viton or EPDM
Case Material
Stainless Steel
Socket Material
Aluminum/Buna-N
Pressure Gauge Type
Differential Pressure Gauge
Panel Mount Characteristics
3 0.162 in Dia Holes on 3.86 in Dia Bolt Circle
Blowout Safety Back
No
Panel-Mountable
Yes
Removable Bezel
No
Hazardous Location Rating
Not Rated
Includes Calibration Certificate
No
Compatible Process Media
Air, Noncorrosive Liquid
Includes Mounting Hardware
No
Lens Material
Glass
Dial Color
White
Sensor Material
Buna-N
Gauge Case Material
Stainless Steel
Primary Scale Minor Graduations
5
Includes Vent Plug
No
Process Temperature Range
32 Degrees to 175 Degrees F
Maximum Working Static Pressure
6,000 psig
IP/NEMA Rating
IP65
Non-Sparking
No
Adjustable Set Points
Yes
Case Shape
Round
Ambient Operating Temperature Range
0 Degrees to 170 Degrees F
Movement Type
Rotary
O-Ring Material
Buna-N
Operating Temperature - Maximum
170 Degrees F
Process Media Temperature - Maximum
175 Degrees F
Number of Switches
0
Process Media Temperature - Minimum
32 Degrees F
Pressure Measurement - Maximum
60 psid
Pressure Scale Minor Graduations
5
IP Rating
IP65
Operating Temperature - Minimum
0 Degrees F
Pressure Measurement - Minimum
0 psid
Working Static Pressure - Maximum
6,000 psig
Product Type
Differential Pressure Gauge

Description

Differential Pressure Gauge, Gauge Nominal Dial Size 3-1/2 In., Basic Gauge Case Material Metal, Basic Gauge Wetted Parts PTFE / Buna-N / Viton or EPDM, Differential Gauge Connection Type FNPT, Differential Gauge Connection Size 1/4 In., Gauge Connection Location Inline, Differential Pressure Range Units psi, Differential Pressure Range Value 0 to 60, Gauge Accuracy +/-2.00 Percent, Body Material Aluminum, Gauge Primary Range Smallest Graduation 5, Diaphragm Material Buna-N, Piston Material PTFE
