Shop ASHCROFT

Pressure Switch, Standard, SPDT, 4 Ports, 1/4" FNPT, 1.5 to 15 psi Range

  • Mfr # B424VXCYLM15

  • Zoro # G1648157

CAD Available
product price:  $204.99
/ea
Free Shipping & Returns

Key Features

CAD Drawing
Action
Standard
Contact Form
SPDT
Number of Pressure Connection Ports
4
Pressure Connection Type
1/4" FNPT
Range
1.5 to 15 psi
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
B424VXCYLM15
Zoro #
G1648157
UPC #
783156420242
Country of Origin
United States

Dimensions

Manufacturer Warranty Length
1 yr
Overall Width
4 in
Overall Depth
3.31 in
Overall Height
5.11 in

Details

Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Number of Pressure Connection Ports
4
Pressure Connection Type
1/4" FNPT
Range
1.5 to 15 psi
Factory On Setting
1.5 psi
Factory Off Setting
15 psi
Standards
3A Approved, CE, CRN, FM Listed, RoHS, UL Listed
AC Contact Rating
15A @ 125/250/480V
Series
B
DC Contact Rating
0.25A @ 250V, 0.5A @ 125V, 6A @ 30V
Actuation Type
Diaphragm
Pressure Switch Electrical Contact Form
SPDT
Pressure Switch Port Type
(1) Port, 1/4 in FNPT
Pressure Switch Factory On/Off Setting
90% of Range
Pressure Switch Differential
0.5 to 1.5 psi
IP Rating
IP66
Pressure Switch Range
1.5 to 15 psi
Media Temperature - Maximum
70 Degrees F
Differential Pressure - Minimum
0.5 psi
Deadband Adjustability
Adjustable
Pressure - Maximum
15 psi
Hazardous Location Specification
Class I, Div 1, Group B, C, D, Class II, Div 1, Group E, F, G
Proof Pressure
500 psi
Differential Pressure - Maximum
1.5 psi
Pressure - Minimum
1.5 psi
Media Temperature - Minimum
50 Degrees F
CAD Available
Yes
NEMA Enclosure Rating
4X
Operating Temperature - Maximum
150 Degrees F
Operating Temperature - Minimum
-20 Degrees F

Description

Pressure Switch, NEMA Rating 13, 3, 4, 4X, Series B, HP @ 1 Phase - 120V 1/4, Temp. Range 20 Degrees to 300 Degrees F, Standards 3A Approved, CE, CRN, FM Listed, RoHS, UL Listed, Special Features Viton(R) Diaphragm, Watertight Enclosure, AC Contact Rating 15 A @ 125 V, 15 A @ 250 V, 15 A @ 480 V
