Voltage Sensor Relay
Mfr # TDT120AKA060
Zoro # G816497954
product price:Â $263.99
/ea
Free Shipping & Returns
Key Features
Mechanical Operating Durability
100,000
Number of Pins
8
Electrical Operating Durability
100,000
Body Width
2.75 in
Weight
0.35 lb
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- TDT120AKA060
- Zoro #
- G816497954
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Body Width
- 2.75 in
- Overall Depth
- 1.75 in
- Body Height
- 3.7 in
- Body Depth
- 1.75 in
Details
- Mechanical Operating Durability
- 100,000
- Number of Pins
- 8
- Electrical Operating Durability
- 100,000
- Weight
- 0.35 lb
- Input Voltage
- 110/240V AC/DC
- Standards
- cURus E55826
- Frequency
- 50/60 Hz
- Maximum Operating Temperature
- 131 Degrees F
- Minimum Operating Temperature
- 32 Degrees F
- Item
- Voltage Sensor Relay
- Contact Form
- DPDT
- Current Rating
- 10 A
- Trip Delay
- 0.6 to 60 sec
- Base Shape
- Octal
- Power Consumption
- 3 VA
- Series
- TDT Series
- Adjustment Method
- Knob
- Contact Rating (AC)
- 10 A @ 250V AC (Resistive), 211 VA @ 120V AC (Inductive)
- Contact Rating (DC)
- 10 A @ 24V DC (Resistive)
Description
Voltage Sensor Relay, Base Shape Octal, Current Rating 10 A, Input Voltage 110/240V AC/DC, Number of Pins 8, Contact Form DPDT, Contact Rating (AC) 10 A @ 250V AC (Resistive), 211 VA @ 120V AC (Inductive), Contact Rating (DC) 10 A @ 24V DC (Resistive), Adjustment Method Knob, Body Depth 1.75 in, Body Height 3.7 in, Body Width 2.75 in, Electrical Operating Durability 100,000, Frequency 50/60 Hz, Maximum Operating Temperature 131 Degrees F, Mechanical Operating Durability 100,000
