BOLTED ELECTRIC VALVE
Mfr # MEVX1014
Zoro # G508413569
product price: $1,599.99
/ea
Free Shipping & Returns
Key Features
Pipe Size
1 in
Body Material
Glass-Filled Polypropylene
Ball Material
Stainless Steel
Seat Material
PTFE
Port
Full
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
MEVX1014
Zoro #
G508413569
UPC #
0791206105216
Country of Origin
United States
Dimensions
Pipe Size
1 in
Overall Length
18 in
Connection Size - Side 1
1 in
Connection Size - Side 2
1 in
Nominal Valve Size
1 in
Description
Electrically Actuated Two-Way Ball Valve, Ball Material Stainless Steel, Nominal Valve Size 1 in, Maximum Pressure - Operating 300 psi, Actuator Operation 90 Degrees , Valve Body Style Straight, Seat Material PTFE, Seal Material FKM, Voltage 12V DC, Fail Safe Position Fail Last, IP Rating IP68, Actuator Cycle Time - 90 Degrees 0.75 sec, Valve Construction Three-Piece, Actuator Features Internally Fused/Automatic Reset, Position Indicator, Connection Type - Side 1 Manifold Flange
