Shop BELDEN

Multi-Conductor, 24 AWG, Silver, 0.184 in.

  • Mfr # 9534 0601000

  • Zoro # G3724379

product price:
$
1,440.99
/ea
Free Shipping & Returns

Key Features

Cable Length
1,000 ft
Number of Strands
32
Conductor Gauge
24 AWG
Fire Rating
Commercial
Jacket Color
Chrome
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
9534 0601000
Zoro #
G3724379
UPC #
612825255116
Country of Origin
Mexico

Dimensions

Cable Length
1,000 ft
Outside Diameter
0.2 in
Spool Length
1,000 ft
Conductor Size - Data Cable
24 AWG
Conductor Size
24 AWG
Length
1000 ft.
Nominal Outside Dia.
0.184 in
Bend Radius
2 1/4 in

Details

Item
Communication Cable
Number of Strands
32
Conductor Gauge
24 AWG
Fire Rating
Commercial
Jacket Color
Chrome
Jacket Material
PVC
Number of Conductors
4
Solid/Stranded
Stranded
Shielding Material
Foil
Maximum Voltage Rating
300 V
NEC Article and Type
800 CMG
Standards
APAC Compliance-China RoHS Compliant II (GB/T 26572-2011), AWM 2464, CMG, CPR Euroclass: Eca, CPR UKCA Class: Eca, EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), NEC Article 800 CMG, UKCA Mark, UL 1685 FT4 Loading, FT4, IEC 60332-1-2
Temp. Range
-22 Degrees to 176 Degrees F
Package Type - Data Cable
Reel in a Box
Fire Rating - Data Cable
Commercial
Shielded
Shielded
Total Number of Conductors - Data Cable
4 (0 Pair)
Cable Sub-Category
Multi-Conductor
Application - Communication Cable
Computer Systems
Insulation Material
PVC
Suggested Voltage Rating - Data Cable
300 V
Application
Computer Systems, Audio Systems, Instrumentation Systems
Jacket Material - Wire and Cable
PVC
Item - Data Cable
Communication Cable
Shielded / Unshielded
Shielded
Solid / Stranded
Stranded
Plenum / Riser Rated
Riser Rated
Package Type
Reel in a Box
Product Type
Communication Cable
Maximum Current
1.8 A
Maximum Impedance
25 ohm
Resistance Properties
Flame/Fire Resistant
Minimum Operating Temperature
-22 Degrees F
Maximum Capacitance
33.0 pf/ft (Nominal Capacitance Conductor to Conductor); 65.0 pf/ft (Nominal Capacitance Conducotr to Other (Conductor + Shield))
Maximum Operating Temperature
176 Degrees F
Number of Pairs
0

Description

Communication Cable, Cable Length 1,000 ft, Fire Rating Commercial, Number of Strands 32, Conductor Gauge 24 AWG, Insulation Material PVC, Jacket Color Chrome, Jacket Material PVC, Shielded Shielded, Shielding Material Foil, Solid/Stranded Stranded, Number of Conductors 4, Outside Diameter 0.2 in, Package Type Reel in a Box, Application Computer Systems, Audio Systems, Instrumentation Systems, Maximum Voltage Rating 300 V, NEC Article and Type 800 CMG, Number of Pairs 0
