Brad Harrison

External Thread Connector, 5, Female, PG7

product price: $25.85
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Number of Pins 5
  • Cable Length 3.30mm to 6.60mm
  • Plug or Connector Type Female
  • Plug End 90 Degrees
  • Max. Voltage 30VAC/36VDC
See all product information

Product Information

Dimensions

Cable Length 3.30mm to 6.60mm
Wire Size 18 AWG
Face Dia. 0.79 in
Cable Diameter 3.30-6.60mm (.130-.260")
Wire Size AWG 18
Connector Mating Size M12x1

Details

Item Field Attachment Connector
Number of Pins 5
Plug or Connector Type Female
Plug End 90 Degrees
Max. Voltage 30VAC/36VDC
Max. Current 4 A
Threads M12
Body Material Polyamide
Standards CSA certified
Color Black
Keyway Single
IP Rating IP68
For Use With All Standard Single Keyway M12 Receptacles And Cordsets
Max. Amps 4A
Features Quick-Disconnect Design; Single Keyway
Temp. Range -13 Degrees to 194 Degrees F
Temperature Range - Operating -25°C to +90°C
Coupling Type Internal Thread
Orientation 90° Angle
CSA LR6837
Poles 5
Current - Maximum per Contact 4.0A
Voltage - Maximum 30V AC / 36V DC
Gender Female
Material - Connector Body PA
Material - Plating Mating Silver
Material - Coupling Nut Nickel-plated Brass
Application/Rating - NEMA NEMA 6P
Angle 90 Degree
Terminals Crimp
Cable Nut Thread PG7
Material PA Body, Nickel Plated Brass Coupling Nut, Silver Plate Mating
Application/Rating - IEC IP67
Connector Type Female Circular Connector
Cable Range 0.13 to 0.26 in.

Description

External Thread Connector, Number of Pins 5, Plug or Connector Type Female, 90 Degrees Plug End, Max. Voltage 30V AC/36V DC, Max. Current 4 A, Wire Size 18 AWG, Threads M12, Face Dia. 0.79 in, Keyway Single, Body Material Polyamide, Color Black, IP Rating 68, Standards CSA Certified
