Mechanical Lug, 1 Conductor, 1 Hole, 3/8 in Stud, Copper
- Mfr # KA25
- Zoro # G4670321
CAD Available
product price:Â
$
10.79
/ea
Key Features
CAD Drawing
Connector Type
Terminal
For Conductor Material
Copper
Number of Conductors
1
Number of Terminations
1
Number of Holes
1
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- KA25
- Zoro #
- G4670321
- UPC #
- 781810554289
- Country of Origin
- United States
Dimensions
- For Stud Size
- 3/8 in
- Hole Diameter
- 0.42 in
- Tongue Width
- 0.75 in
- Stud Size
- 3/8 in
- Width
- 0.94 in
- Max. Conductor Size
- 1/0 AWG Stranded
- Length
- 1.69 in
- Min. Conductor Size
- 4 AWG Stranded
- Length (Straight Wireway)
- 1.69 in
- Tongue Thickness
- 0.13 in
- For Stranded Copper Wire Size - Minimum
- 4 AWG
- For Stranded Copper Wire Size - Maximum
- 1/0 AWG
- Overall Length
- 1.69 in
- Overall Depth
- 3/4 in
- Overall Width
- 0.94 in
- Conductor Size
- 4-1/0 AWG
- Dimension - L Length Overall mm
- 43 mm
- Dimension - Length Overall inch
- 1.69 in
- Conductor - Copper Str Size
- 4 AWG;3 AWG;2 AWG;1 AWG;1/0
- Dimension - Height inch
- 0.94 in
- Dimension - Height fraction
- 15/16
- Dimension - B Length inch
- 0.69 in
- Dimension - Bolt Size fraction
- 2023-03-08
- Dimension - Hole Size mm
- 11 mm
- Dimension - Hole Size inch
- 0.42 in
- Conductor - Copper Str Size Range
- 4 AWG-1/0
- Dimension - Stud Size inch
- 44993
- Dimension - Hole Size fraction
- 27/64
- Dimension - Pad Width inch
- 0.75 in
- Dimension - N inch
- 0.38 in
- Dimension - B Length fraction
- 20/29 in
- Wire Rope Length
- 1.69 in
Description
Mechanical Connector, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 4 AWG, For Stranded Copper Wire Size - Maximum 1/0 AWG, For Stud Size 3/8 in, Head Style Hex Socket, Number of Holes 1, Hole Diameter 0.42 in, Hole Spacing Not Applicable, Body Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 1, Number of Terminations 1, Tongue Length Not Applicable, Tongue Width 0.75 in, Connector Type Terminal
