Shop BURNDY

Mechanical Lug, 1000 kcmil Max, 2 Hole, Not Applicable Stud, Aluminum, Copper

  • Mfr # ASA1000U

  • Zoro # G4701733

product price:  $20.79
/ea

Key Features

For Conductor Material
Aluminum, Copper
For Minimum Wire Size
1/0 AWG
For Maximum Wire Size
1000 kcmil
Number of Conductors
2
Number of Holes
2
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ASA1000U
Zoro #
G4701733
UPC #
781810554715
Country of Origin
United States

Dimensions

For Minimum Wire Size
1/0 AWG
For Maximum Wire Size
1000 kcmil
Tongue Width
1.25 in
Width
1.25 in
Max. Conductor Size
1000 kcmil Stranded
Length
1.25 in
Min. Conductor Size
1/0 AWG Stranded
Length (Straight Wireway)
1.25 in
Overall Width
1.25 in
Overall Length
0.91 in
For Stranded Copper Wire Size - Minimum
1/0 AWG
For Stranded Copper Wire Size - Maximum
1000 kcmil
Overall Depth
1 1/4 in
Conductor - Copper Str Size
1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil;300 kcmil;350 kcmil;400 kcmil;450 kcmil;500 kcmil;550 kcmil;600 kcmil;700 kcmil;750 kcmil;800 kcmil;850 kcmil;900 kcmil;1000 kcmil
Conductor - AL Str Size
1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil;266 kcmil;300 kcmil;336 kcmil;350 kcmil;397 kcmil;400 kcmil;450 kcmil;477 kcmil;500 kcmil;550 kcmil;556 kcmil;600 kcmil;636 kcmil;650 kcmil;700 kcmil;715 kcmil;750 kcmil;795 kcmil;800 kcmil;874 kcmil;900 kcmil;954 kcmil;1000 kcmil
Dimension - Height fraction
1-1/4 in
Dimension - Length Overall inch
0.91 in
Dimension - Height inch
1.25 in
Dimension - Pad Width inch
1.25 in
Dimension - L Length Overall mm
23 mm
Conductor - AL Str Size Range
1/0 AWG-1000 kcmil
Conductor - Copper Str Size Range
1/0 -1000 kcmil
Dimension - Bolt Size inch
3.75 in

Details

Item
Mechanical Lug
For Conductor Material
Aluminum, Copper
Number of Conductors
2
Number of Holes
2
Body Material
Aluminum, Copper
Contact Finish
Tin
Maximum Voltage
600 V
Maximum Operating Temperature
194 Degrees F
Standards
CSA Certified, UL Listed
Material
Tin-Plated Aluminum
Special Features
The HYSTACK Adaptor Is Specially Designed To Allow Standard Terminals To Be Stacked On Two Or Four Hole NEMA Transformer Or Equipment Terminal Pads, HYSTACK Is Tin-Plated, High-Conductivity Aluminum To Provide Optimum Corrosion Resistance, Only Three Sizes Accommodate Terminals From 250 MCM Through 1000 MCM To Help Keep Costly Inventories To A Minimum
RoHS Compliant
Yes
Type
Stacking Adapters
Physical Attribute - Number of Screws
2
Rating - Minimum Voltage
600
Physical Attribute - Number of Holes
2
Application
For Aluminum And Copper Terminals
Certification - UL Listed Direct Burial
No
Conductor Type
AL C Str-SizeCU C Str-Size
UL Listed
Yes
Physical Attribute - Screw Type
Hexagonal Bolt
Certification - CSA Approved
Yes
Trade Name
HYSTACKâ„¢
Plating Type
Tin
Installation Torque Recommended in-lb
480 LBS/in
Plated
Y
Material - Hardware
DURIUMâ„¢ Silicon Bronze
Temperature Rating
194° F
Connector Type
Stacking Adaptor
Head Style
Hex

Description

Mechanical Connector, For Conductor Material Aluminum, Copper, For Stranded Copper Wire Size - Minimum 1/0 AWG, For Stranded Copper Wire Size - Maximum 1000 kcmil, For Stud Size Not Applicable, Head Style Hex, Number of Holes 2, Hole Diameter Not Applicable, Hole Spacing Not Applicable, Body Material Aluminum, Max. Operating Temp. 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 2, Number of Terminations Not Applicable, Tongue Width 1.25 in, Tongue Thickness Not Applicable
