Burndy One-Hole Compression Lug, 3/0 AWG Max, 1/2 in Stud, Long Barrel, Copper, None YAD27M12E12 - main

One-Hole Compression Lug, 3/0 AWG Max, 1/2 in Stud, Long Barrel, Copper, None

  • Mfr # YAD27M12E12

  • Zoro # G6079753

product price: $13.49
/ea

Key Features

For Wire Size
3/0 AWG
For Conductor Material
Copper
For Stud Size
1/2 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
YAD27M12E12
Zoro #
G6079753
UPC #
781810668276
Country of Origin
Taiwan, Province of China

Dimensions

For Wire Size
3/0 AWG
For Stud Size
1/2 in
Barrel Size
Long
Tongue Width
0.95 in
Overall Length
2.13 in
Cable Size
3/0 AWG
Barrel Length
0.79 in
Length
2.13"
Tongue Width - Wire Connector
0.95 in
Width
0.95"
Hole Diameter
0.51 in
Tongue Thickness
0.1 in
Minimum Wire Size
3/0 AWG
Tongue Length
1.34 in
Maximum Wire Size
3/0 AWG
Barrel Outside Diameter
0.79 in
Strip Length
7/8 in
Dimension - L Length Overall mm
54 mm
Dimension - Stud Size inch
3/8 1/2
Dimension - Outside Diameter inch
0.79 in
Dimension - Bolt Size fraction
1 to 2
Dimension - Hole Size inch
0.41 in 0.51 in
Conductor Size
3/0 AWG
Dimension - Strip Length inch
45115
Conductor - Copper Str Size
3/0 AWG
Dimension - B Length inch
0.79 in
Dimension - Length Overall inch
2.13 in
Dimension - Pad Width inch
0.95 in

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Inspection Hole
No
Die Code
1023
Color Code
None
Standards
UL 467
Insulation Type
Non-Insulated
Tongue Style
Ring
Connection Material
Tin Plater Copper
Plate Material
Tin
Wire Range
3/0 AWG
Connector Type
YAD
Seam
Brazed
Hole Center to End
1.650"
Max. Voltage
600 V
Max. Temp.
302 Degrees F
Insulation Color
Bare
Peep Hole
No
Maximum Voltage
600 V
Hole Spacing
0.86 in
Compatible with Series
PAT4PC834, PAT750, PAT81KFT, Y35, Y39, Y4PC834, Y750, Y81KFT
Contact Material
Copper
Insulation Material
None
Barrel Style
Brazed
Contact Finish
Tin
Seam Style
Brazed
Terminal Shape
Ring Tongue
Minimum Operating Temperature
302 Degrees F
Maximum Operating Temperature
302 Degrees F
RoHS Compliant
Yes
Special Features
Durable Long Lasting Corrosion Resistance, Vibration Resistance and Tensile Strength, Provide Execellent High Conductivity Connections
Insulation Coverage
None
Termination Style
Crimp
Compatible with Product Type
Code, Flex Cable
Plating Type
Tin
Item Type
3B
Feature - Barrel Type
Long
Physical Attribute - Tongue Type
Ring
Type
Ring Tongue
Application
The YAD uninsulated OEM lug terminal is constructed of electrolytic copper
Conductor Type
CU C Str-SizeCU C Flex-Size
Plated
Y
Voltage - Maximum
600 V
Industry Standard(s)
UL467
Trade Name
HYLUGâ„¢
Number of Holes
1

Description

Ring Terminal, Insulation Color Bare, Insulation Coverage None, Insulation Material None, Maximum Temperature 302 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 3/0 AWG, Maximum Wire Size 3/0 AWG, Termination Style Crimp, Tongue Width 0.95 in, Contact Finish Tin, Contact Material Copper, Standards UL 467, Barrel Length 0.79 in, Barrel Outside Diameter 0.79 in, Barrel Size Long, Barrel Style Brazed, Compatible Grainger Part Number 22P219, 22P221, Compatible with Product Type Code, Flex Cable
