  11. One-Hole Compression Lug, 350 kcmil Max, 5/8 in Stud, Short Barrel, Copper, Brown
Burndy One-Hole Compression Lug, 350 kcmil Max, 5/8 in Stud, Short Barrel, Copper, Brown YA34LB - main

One-Hole Compression Lug, 350 kcmil Max, 5/8 in Stud, Short Barrel, Copper, Brown

  • Mfr # YA34LB

  • Zoro # G4658437

product price: $30.55
/ea

Key Features

Cable Size
350 Kcmil to 400 kcmil
Connector Type
Short Barrel
Width
1.52"
Material
Copper
Length
3.56"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
YA34LB
Zoro #
G4658437
UPC #
781810556023
Country of Origin
United States

Dimensions

Cable Size
350 Kcmil to 400 kcmil
Width
1.52"
Length
3.56"
Barrel Length
Short
Length (Straight Wireway)
3.56 in
For Wire Size
350 kcmil
Dimension - Outside Diameter inch
1.06 in
Dimension - Z inch
0.67 in
Conductor - Copper Flex M Size
350 kcmil
Dimension - Bolt Hole Size inch
0.66 in
Dimension - Hole Size fraction
2023-05-08
Dimension - Bolt Size inch
0.63
Dimension - Bolt Size fraction
45054
Dimension - B Length inch
1.35 in
Conductor - Copper Flex H Size Range
350 kcmil-400 kcmil
Conductor - Copper Flex K Size
350 kcmil
Conductor - Copper Flex I Size Range
350 kcmil-400 kcmil
Dimension - Strip Length inch
42376
Dimension - N inch
0.66 in
Conductor - Copper Str Size
500 kcmil
Dimension - Hole Size inch
0.69 in
Conductor - Copper Flex H Size
350 kcmil;400 kcmil
Dimension - B Length fraction
1-3/8 in
Dimension - Hole Size mm
18 mm
Conductor - Copper Flex G Size
350 kcmil;400 kcmil
Conductor - Copper Flex K Size Range
350 kcmil
Conductor - Copper Flex I Size
350 kcmil;400 kcmil
Conductor - Copper Flex G Size Range
350 kcmil-400 kcmil
Conductor - Copper DLO Size
373.7 (925/#24) DLO
Conductor - Copper DLO Size Range
373.7 (925/#24) DLO
Dimension - Stud Size fraction
2023-05-08
Conductor - Copper Flex M Size Range
350 kcmil
Dimension - Length Overall inch
3.56 in
Dimension - L Length Overall mm
90 mm
Conductor - Copper Str Size Range
350 kcmil
Conductor Size
500 KCMIL
Dimension - Pad Width inch
38.6 in
For Stud Size
5/8 in
Tongue Width
1.52 in
Barrel Size
Short

Details

Connector Type
Short Barrel
Material
Copper
Color Code
Brown
Tongue Style
Standard
Standards
CSA Certified, UL 486A-486B, UL Listed
Hole Center to End
0.66 in
Peep Hole
Yes
Item
One-Hole Compression Lug
Plate Material
Electro Tin
Die Code
1,027
Application
For Flex Conductor
Trade Name
HYLUGâ„¢
Physical Attribute - Tongue Type
Standard
Voltage - Maximum
35000
Plated
Y
UL Listed
Yes
Feature - Barrel Style
Belled
Die Index
20;1027
Feature - Barrel Type
Standard
Conductor Type
CODE
Finish Type
Tin-Plated
Plating Type
Tin - Electro Plated
Rating - KVA
35 kV
Type
Standard Belled Barrel, Tin Plated
Rating - Minimum Voltage
600
Certification - CSA Approved
Yes
Conductor - Material
Copper
Physical Attribute - Number of Holes
1
Industry Standard(s)
UL468A-468B
Physical Attribute - Tongue Angle
Straight
Voltage Rating
35 kV
Tongue Angle
Straight
Number of Holes
1
For Conductor Material
Copper
Inspection Hole
Yes

Description

One-Hole Lug Compression Connector, Color Code Brown, Die Code 1,027, For Stud Size 5/8 in, Hole Center to Center Not Applicable, Material Copper, Maximum Operating Temperature 194 Degrees F, Standards CSA Certified, UL 486A-486B, UL Listed, Connector Type Belled Straight Barrel
