  11. One-Hole Compression Lug, 8 AWG Max, 5/16 in Stud, Long Barrel, Copper, None, 10 PK
Burndy One-Hole Compression Lug, 8 AWG Max, 5/16 in Stud, Long Barrel, Copper, None, 10 PK YAD8CM8E516 - main

One-Hole Compression Lug, 8 AWG Max, 5/16 in Stud, Long Barrel, Copper, None, 10 PK

  • Mfr # YAD8CM8E516

  • Zoro # G6202847

product price: $10.69
/pk 10, $1.07/ea

Key Features

For Wire Size
8 AWG
For Conductor Material
Copper
For Stud Size
5/16 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
YAD8CM8E516
Zoro #
G6202847
UPC #
781810668771
Country of Origin
Taiwan, Province of China

Dimensions

For Wire Size
8 AWG
For Stud Size
5/16 in
Barrel Size
Long
Tongue Width
0.55 in
Width
0.55"
Cable Size
8 AWG
Overall Length
1.06 in
Length
1.06"
Barrel Length
0.31 in
Tongue Width - Wire Connector
0.55 in
Strip Length
3/8 in
Barrel Outside Diameter
0.26 in
Tongue Thickness
0.04 in
Hole Diameter
0.33 in
Maximum Wire Size
8 AWG
Minimum Wire Size
8 AWG
Tongue Length
0.75 in
Dimension - Pad Width inch
0.55 in
Conductor - Copper Str Size
8 AWG
Dimension - Strip Length inch
44993
Dimension - L Length Overall mm
27 mm
Dimension - Length Overall inch
1.06 in
Dimension - Outside Diameter inch
0.26 in
Dimension - Bolt Size fraction
2023-05-16
Dimension - Hole Size inch
0.33 in
Dimension - B Length inch
0.31 in
Conductor Size
8 AWG
Dimension - Stud Size inch
45062

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Inspection Hole
No
Die Code
1013
Color Code
None
Standards
UL 467
Seam
Brazed
Max. Temp.
302 Degrees F
Wire Range
8 AWG
Connector Type
YAD
Tongue Style
Ring
Insulation Type
Non-Insulated
Hole Center to End
0.790"
Insulation Color
Bare
Peep Hole
No
Max. Voltage
600 V
Plate Material
Tin
Connection Material
Tin Plater Copper
Barrel Style
Brazed
Maximum Voltage
600 V
Contact Finish
Tin
RoHS Compliant
No
Insulation Material
None
Seam Style
Brazed
Maximum Operating Temperature
302 Degrees F
Termination Style
Crimp
Minimum Operating Temperature
302 Degrees F
Compatible Manufacturer Model Number
PAT4PC834-18, PAT81KFT-18V
Terminal Shape
Ring Tongue
Hole Spacing
0.48 in
Compatible with Series
PAT4PC834, PAT81KFT, Y4PC834, Y81KFT
Compatible with Product Type
Code, Flex Cable
Insulation Coverage
None
Special Features
Resists Overheating and Corrosion
Contact Material
Copper
Trade Name
HYLUGâ„¢
Conductor Type
CU C Str-SizeCU C Flex-Size
Type
Ring Tongue
Plating Type
Tin
Voltage - Maximum
600 V
Industry Standard(s)
UL467
Item Type
3B
Plated
Y
Physical Attribute - Tongue Type
Ring
Feature - Barrel Type
Long
Application
The YAD uninsulated OEM lug terminal is constructed of electrolytic copper

Description

Ring Terminal, Insulation Color Bare, Insulation Coverage None, Insulation Material None, Maximum Temperature 302 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 8 AWG, Maximum Wire Size 8 AWG, Termination Style Crimp, Tongue Width 0.55 in, Contact Finish Tin, Contact Material Copper, Standards UL 467, Barrel Length 0.31 in, Barrel Outside Diameter 0.26 in, Barrel Size Long, Barrel Style Brazed, Compatible Grainger Part Number 22P219, 22P221
