  11. Two-Hole Compression Lug, 350 kcmil Max, 1/2 in Stud, Long Barrel, Copper, Red
Burndy Two-Hole Compression Lug, 350 kcmil Max, 1/2 in Stud, Long Barrel, Copper, Red YA312N - main

Two-Hole Compression Lug, 350 kcmil Max, 1/2 in Stud, Long Barrel, Copper, Red

  • Mfr # YA312N

  • Zoro # G0693997

product price: $14.75
/ea

Key Features

Material
Copper
Color Code
Red
Standards
UL468A-468B
Die Code
18, 324
Hole Center to Center
1.75 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
YA312N
Zoro #
G0693997
UPC #
781810505205
Country of Origin
Unknown

Dimensions

Conductor - AL Str Size
350 kcmil
Dimension - Z inch
0.63 in
Conductor - Copper Str Size
350 kcmil
Dimension - B Length fraction
2 in
Dimension - N inch
0.62 in
Dimension - Length Overall inch
5.69 in
Dimension - Strip Length inch
42401
Dimension - Bolt Hole Size inch
0.52 in
Dimension - Hole Size inch
0.56 in
Dimension - Outside Diameter inch
0.88 in
Dimension - Stud Size inch
1 to 2
Dimension - L Length Overall mm
144 mm
Dimension - Bolt Size fraction
1 to 2
Dimension - Pad Width inch
1.29 in
Dimension - B Length inch
2.00 in
Dimension - Hole Size mm
14 mm
Conductor Size
350 KCMIL
Dimension - Bolt Size inch
0.5
Dimension - Stud Size fraction
1 to 2
Dimension - Hole Size fraction
1 to 2
Conductor - Copper Str Size Range
350 kcmil
Stud Hole Size (In.)
1/2"
For Wire Size
350 kcmil
Tongue Width
1.29 in
For Stud Size
1/2 in
Barrel Size
Long

Details

Material
Copper
Color Code
Red
Standards
UL468A-468B
Item
Two-Hole Compression Lug
Die Code
18, 324
Hole Center to Center
1.75 in
Gauge
350KCMIL (AKA MCM)
Plated
Y
Type
Long Barrel, Tin Plated
Conductor - Material
Copper
Certification - CSA Approved
Yes
Plating Type
Tin
Die Index
18;324
Physical Attribute - Number of Holes
2
Rating - Minimum Voltage
600
Industry Standard(s)
UL468A-468B
Feature - Barrel Style
Chamfered
Rating - KVA
35 kV
Feature - Barrel Type
Long
Physical Attribute - Tongue Angle
Straight
Application
For Code Conductor
Physical Attribute - Tongue Type
Standard
Voltage - Maximum
35000
UL Listed
Yes
Conductor Type
CODE
Finish Type
Tin-Plated
Voltage Rating
35 kV
Trade Name
HYLUG™
Bolt Hole
1/2 in
Stud Hole Spacing (In.)
1.75 in
Center Spacing
1 3/4 in
For Conductor Material
Copper
Number of Holes
2
Tongue Angle
Straight
