118PC 118 Degree General Purpose Jobber Lengh Drill Set Chicago-Latrobe 150 Steam Oxide HSS 1mm-13mmx.1mm

  • Mfr # 57727

  • Zoro # G3264764

product price:
$
558.99
/ea
Free Shipping & Returns

Key Features

Number of Pieces
118
Cutting Direction
Right Hand
Drill Bit Point Angle
118 Degrees
Drill Bit Material
High Speed Steel
Includes
Metal Drill Index
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
57727
Zoro #
G3264764
UPC #
662355577271
Country of Origin
United States

Dimensions

Depth:Dia. Ratio
4xD
Sizes Included
1.00mm, 1.20mm, 1.30mm, 1.40mm, 1.50mm, 1.60mm, 1.70mm, 1.80mm, 1.90mm, 2.00mm, 2.10mm, 2.20mm, 2.30mm, 2.40mm, 2.50mm, 2.60mm, 2.70mm, 2.80mm, 2.90mm, 3.00mm, 3.10mm, 3.20mm, 3.30mm, 3.40mm, 3.50mm, 3.60mm, 3.70mm, 3.80mm, 3.90mm, 4.00mm, 4.10mm, 4.20mm, 4.30mm, 4.40mm, 4.50mm, 4.60mm, 4.70mm, 4.80mm, 4.90mm, 5.00mm, 5.10mm, 5.20mm, 5.30mm, 5.40mm, 5.50mm, 5.60mm, 5.70mm, 5.80mm, 5.90mm, 6.00mm, 6.10mm, 6.20mm, 6.30mm, 6.40mm, 6.50mm, 6.60mm, 6.70mm, 6.80mm, 6.90mm, 7.00mm, 7.10mm, 7.20mm, 7.30mm, 7.40mm, 7.50mm, 7.60mm, 7.70mm, 7.80mm, 7.90mm, 8.00mm, 8.10mm, 8.20mm, 8.30mm, 8.40mm, 8.50mm, 8.60mm, 8.70mm, 8.80mm, 8.90mm, 9.00mm, 9.10mm, 9.20mm, 9.30mm, 9.40mm, 9.50mm, 9.60mm, 9.70mm, 9.80mm, 9.90mm, 10.00mm, 10.10mm, 10.20mm, 10.30mm, 10.40mm, 10.50mm, 10.60mm, 10.70mm, 10.80mm, 10.90mm, 11.00mm, 11.10mm, 11.20mm, 11.30mm, 11.40mm, 11.50mm, 11.60mm, 11.70mm, 11.80mm, 11.90mm, 12.00mm, 12.10mm, 12.20mm, 12.30mm, 12.40mm, 12.50mm, 12.60mm, 12.70mm, 12.80mm, 12.90mm, 13.00mm
Drill Bit Dimension Type
Metric
Drill Bit Size
1 mm to 13 mm by 0.1 mm
Depth x Dia. Ratio
4xD
Shank Dia.
197/5000 in
Drill Length Class
Jobber-Length
Smallest Drill Bit Size
1 mm
Drill Bit Sizes Included
1 mm, 1.1 mm, 1.2 mm, 1.3 mm, 1.4 mm, 1.5 mm, 1.6 mm, 1.7 mm, 1.8 mm, 1.9 mm, 10 mm, 10.1 mm, 10.2 mm, 10.3 mm, 10.4 mm, 10.5 mm, 10.6 mm, 10.7 mm, 10.8 mm, 10.9 mm, 11 mm, 11.1 mm, 11.2 mm, 11.3 mm, 11.4 mm, 11.5 mm, 11.6 mm, 11.7 mm, 11.8 mm, 11.9 mm, 12 mm, 12.1 mm, 12.2 mm, 12.3 mm, 12.4 mm, 12.5 mm, 12.6 mm, 12.7 mm, 12.8 mm, 12.9 mm, 13 mm, 2 mm, 2.1 mm, 2.2 mm, 2.3 mm, 2.4 mm, 2.5 mm, 2.6 mm, 2.7 mm, 2.8 mm, 2.9 mm, 3 mm, 3.1 mm, 3.2 mm, 3.3 mm, 3.4 mm, 3.5 mm, 3.6 mm, 3.7 mm, 3.8 mm, 3.9 mm, 4 mm, 4.1 mm, 4.2 mm, 4.3 mm, 4.4 mm, 4.5 mm, 4.6 mm, 4.7 mm, 4.8 mm, 5 mm, 5.1 mm, 5.2 mm, 5.3 mm, 5.4 mm, 5.5 mm, 5.6 mm, 5.7 mm, 5.8 mm, 6 mm, 6.1 mm, 6.2 mm, 6.3 mm, 6.4 mm, 6.5 mm, 6.6 mm, 6.7 mm, 6.8 mm, 6.9 mm, 7 mm, 7.1 mm, 7.2 mm, 7.3 mm, 7.4 mm, 7.5 mm, 7.6 mm, 7.7 mm, 7.8 mm, 7.9 mm, 8 mm, 8.1 mm, 8.2 mm, 8.3 mm, 8.4 mm, 8.5 mm, 8.6 mm, 8.7 mm, 8.8 mm, 8.9 mm, 9 mm, 9.1 mm, 9.2 mm, 9.3 mm, 9.4 mm, 9.5 mm, 9.6 mm, 9.7 mm, 9.8 mm, 9.9 mm, mmm
Largest Drill Bit Size
13 mm
Overall Length
1 11/32 in, 1 27/64 in, 1 1/2 in, 1 9/16 in, 1 11/16 in, 1 13/16 in, 1 15/16 in, 2 3/32 in, 2 15/64 in, 2 13/32 in, 2 9/16 in, 2 49/64 in, 2 61/64 in, 3 5/32 in, 3 25/64 in, 3 21/32 in, 3 63/64 in, 4 19/64 in, 4 39/64 in, 4 59/64 in, 5 15/64 in, 5 19/32 in, 5 15/16 in
Size Range
1mm-13mm
Wire Rope Length
1 11/32 in, 1 27/64 in, 1 1/2 in, 1 9/16 in, 1 11/16 in, 1 13/16 in, 1 15/16 in, 2 3/32 in, 2 15/64 in, 2 13/32 in, 2 9/16 in, 2 49/64 in, 2 61/64 in, 3 5/32 in, 3 25/64 in, 3 21/32 in, 3 63/64 in, 4 19/64 in, 4 39/64 in, 4 59/64 in, 5 15/64 in, 5 19/32 in, 5 15/16 in

Details

Item
Jobber Length Drill Bit Set
Number of Pieces
118
Cutting Direction
Right Hand
Drill Bit Point Angle
118 Degrees
Drill Bit Material
High Speed Steel
Includes
Metal Drill Index
Drill Bit Grouping
Drill Bit Set
List Number
150
Standards
DIN 338
Flute Type
Spiral
Measurement System
Metric
Shank Type
Straight
Aircraft Drill
No
Drill Bit Point Type
Conventional Point
Material Grade - Machining
General Purpose
Coolant Fed
Non-Coolant Through
Primary Material Application
Cast Iron, Steel
Shank Type - Machining
Straight
Number of Drill Bits
118
Material - Machining
High Speed Steel
Finish - Machining
Black Oxide
Drill Bit Case Type
Metal Index
Number of Flutes
2
Primary Material Application ISO Code
K, P
Spiral Direction
Right Hand
Drill Style
Jobber Drill
Left/Right Hand
Right
Point Type
Conventional Point
Helix Angle - Maximum
34 Degrees
Helix Angle - Minimum
21 Degrees

Description

The CHICAGO-LATROBE - 57727 is a jobber-length drill bit set comprising 118 high speed steel drill bits with sizes ranging from 1 mm to 13 mm in 0.1 mm increments. The bits feature a conventional point with a 118-degree angle and are designed for right-hand cutting direction. The set includes a metal drill index for organization and is recommended for drilling cast iron and steel. The bits have two flutes with spiral right-hand geometry and a black oxide finish for machining applications. The set meets the dimensional and performance requirements of DIN 338 standards.

Key Features:

  • Number of pieces: 118 drill bits
  • Size range: 1 mm to 13 mm, increments of 0.1 mm
  • Material: High speed steel (HSS) drill bits, general purpose grade
  • Point angle: 118 degrees, conventional type
  • Flute design: Two-flute spiral with helix angle between 21° and 34°
  • Shank type: Straight shank with 0.197 inch diameter
  • Drill length class: Jobber length
  • Finish: Black oxide
  • Cutting direction: Right hand
  • Application materials: Cast iron and steel (ISO K, P)
  • Includes metal drill index for bit storage and organization
  • Meets the dimensional and performance requirements of DIN 338
