11PC 135 Degree Heavy-Duty Jobber Length Drill Set Cle-Line 1878 Black & Gold HSS 1mm-6mmx.5mm
Mfr # C74058
Zoro # G2827507
Key Features
Specifications
Product Information
- MFR #
- C74058
- Zoro #
- G2827507
- UPC #
- 662355740583
- Country of Origin
- United States
Dimensions
- Drill Bit Dimension Type
- Metric
- Drill Bit Size
- 1 mm to 6 mm by 0.5 mm
- Sizes Included
- 1/16",5/64",3/32",7/64",1/8",9/64",5/32",11/64",3/16",13/64",7/32",15/64",1/4"
- Shank Dia.
- 1/16 in
- Depth x Dia. Ratio
- 4xD
- Size Range
- #1-#60
- Depth:Dia. Ratio
- 4xD
- Drill Bit Sizes Included
- 1 mm, 1.5 mm, 2 mm, 2.5 mm, 3 mm, 3.5 mm, 4 mm, 4.5 mm, 5 mm, 5.5 mm, 6 mm
- Drill Length Class
- Jobber-Length
- Largest Drill Bit Size
- 6 mm
- Smallest Drill Bit Size
- 1 mm
- Overall Length
- 1 11/32 in, 1 9/16 in, 1 15/16 in, 2 15/64 in, 2 13/32 in, 2 49/64 in, 2 61/64 in, 3 5/32 in, 3 25/64 in, 3 21/32 in
Description
The CLE-LINE C74058 is a jobber-length drill bit set. The set includes 11 high speed steel (HSS) drill bits with sizes ranging from 1 mm to 6 mm, rated for drilling aluminum, cast iron, and steel within standard drill-bit use (material-specific results depend on cutting speed, feed rate, coolant/lubrication, and workpiece hardness). Each bit features a split point tip and a right-hand spiral direction, with a right-hand spiral/flute geometry for chip evacuation during drilling. The bits come in a metal index case. This set complies with applicable ASME B94.11M and DIN 338 specifications.
Key Features:
- Drill bit material: high speed steel (HSS) drill bit material for machining.
- Jobber length drill style with varied overall lengths between 1 11/32" and 3 21/32".
- Metric size range from 1 mm to 6 mm with 11 pieces included.
- Split point type with a 135-degree point angle for precise starts and reduced walking.
- Spiral flute design with right-hand cutting direction and a helix angle between 21° and 34°.
- Straight shank with three flats and 1/16" diameter for secure chuck grip.
- Includes a metal drill index case for bit organization and storage.
