  6. 3" X 1-1/4" Non-Marking Rubber Hi-Tech Swivel Caster, Side Brake, Loads Up To 150 lb
Colson 3" X 1-1/4" Non-Marking Rubber Hi-Tech Swivel Caster, Side Brake, Loads Up To 150 lb 2.03356.42 BRK1 - main

3" X 1-1/4" Non-Marking Rubber Hi-Tech Swivel Caster, Side Brake, Loads Up To 150 lb

  • Mfr # 2.03356.42 BRK1

  • Zoro # G7810497

product price:  $32.85
/ea

Key Features

Caster Frame Material
Steel
Mounting Plate Size
2 1/2 in x 3 5/8 in
Wheel/Tread Material
Rubber
Caster Stem Type
Top Plate
Swivel Radius
3 5/8 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
2.03356.42 BRK1
Zoro #
G7810497
UPC #
-
Country of Origin
China

Dimensions

Mounting Plate Size
2 1/2 in x 3 5/8 in
Swivel Radius
3 5/8 in
Mounting Bolt Dia.
5/16 in
Wheel Width
1 1/4 in
Mounting Height
4-1/8 in
Wheel Dia.
3 in
Outside Slot Spacing - Width
1.75 in
Mounting Plate Thickness
5/32 in
Mounting Plate Length
3 5/8 in
Outside Slot Spacing - Length
3.063 in
Mounting Plate Width
2 1/2 in
For Axle Dia.
3/8 in
Inside Slot Spacing - Length
2.813 in
Inside Slot Spacing - Width
1.75 in

Details

Caster Frame Material
Steel
Wheel/Tread Material
Rubber
Item
Swivel Caster with Brake
Caster Stem Type
Top Plate
Series
2
Wheel Core Material
Polypropylene
Caster Mounting Type
Plate
Load Rating Range
0 to 299 lb
Load Rating
150 lb
Swivel Lock Type
No Lock Included
System of Measurement
Inch
Caster Plate Hole Pattern
C
Wheel Bearing Type
Ball
Operating Temperature Range
-45 Degrees to 180 Degrees F
Application
Store Fixtures, Stoage Equipment, Utility Carts, Institutional Equipment, Office Equipment, Food Service, Material Handling Equipment, Hospitality Carts
Caster Brake Type
Side Brake
Swivel Raceway Type
Double Ball
Non-Marking
Yes
Wheel Core Type
Solid
Tread Shape
Standard
Core Color
Black
Number of Mounting Holes
4
Includes Thread Guards
No
Frame Finish
Zinc Plated
Caster Sub-Type
Swivel
Wheel/Tread Hardness Rating
Soft
Outside Bolt Hole Spacing
1-3/4 in X 3-13/16 in
Number of Wheels
1
Inside Bolt Hole Spacing
1-3/4 in X 2-13/16 in
Load Capacity - Maximum
150 lb
Wheel Hardness Rating
65 Shore A
For Surface Type
Asphalt, Ceramic, Metal Scrap, Rubber, Steel, Tile, Vinyl, Wood
Mounting Plate Shape
Rectangle
Mounting Hole Type
Slot
Brake Location
Left Side

Description

Swivel, Plate Caster, Load Rating 150 lb, Swivel Lock Type No Lock Included, Wheel Dia. 3 in, Wheel Width 1 1/4 in, Wheel/Tread Material Rubber, Wheel Core Material Polypropylene, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Side Brake, Tread Shape Standard
