  7. Miniature Snap Action Switch, Lever Actuator, 1NO, 5 A at 120 V AC Contact Rating
Cpi Miniature Snap Action Switch, Lever Actuator, 1NO, 5 A at 120 V AC Contact Rating K1006-503 - main

Miniature Snap Action Switch, Lever Actuator, 1NO, 5 A at 120 V AC Contact Rating

  • Mfr # K1006-503

  • Zoro # G2349952

product price:  $122.99
/ea
Free Shipping & Returns

Key Features

Actuator Type - Snap Action Switch
Lever
AC Contact Rating - Snap Action Switch
5 A @ 120 V
DC Contact Rating - Snap Action Switch
5 A @ 28 V
Contact Form- Switches
1NO
Height - Snap Action Switch
2.06 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
K1006-503
Zoro #
G2349952
UPC #
-
Country of Origin
United States

Dimensions

Height - Snap Action Switch
2.06 in
Width - Snap Action Switch
0.8 in
Depth - Snap Action Switch
0.94 in
Depth
0.94"
Height
2.06"
Overall Height
2.06 in
Overall Depth
0.94 in
Body Depth
0.94 in
Body Width
0.8 in
Overall Width
0.8 in
Body Height
2.06 in
Roller Width
0.31 in

Details

Item
Miniature Snap Action Switch
Actuator Type - Snap Action Switch
Lever
AC Contact Rating - Snap Action Switch
5 A @ 120 V
DC Contact Rating - Snap Action Switch
5 A @ 28 V
Contact Form- Switches
1NO
Housing Material
Neoprene Rubber Encapsulated
Electrical Connection - Snap Action Switch
Lead Wires
Contact Form
1NO
Series
K1006
Includes
Neoprene Rubber Encapsulated
Terminal Type
Lead Wires
Type of Actuator
Lever
Current Rating
5A
Watertight - Snap Action Switch
Yes
AC Contact Rating
5 A @ 120 V
DC Contact Rating
5 A @ 28 V
Resistance Properties
Watertight
Operating Force - Maximum
48 ozf
Actuator Style
Lever
Roller Adjustability
Fixed
Body Material
Neoprene Rubber
Overtravel
0.25 in
Roller Position
Top
Operating Force - Minimum
16 ozf
Roller Material
Neoprene Rubber
Electrical Connection
Lead Wires

Description

Miniature Snap Action Switch, Lever, AC Contact Rating - Snap Action Switch 5 A @ 120 V, DC Contact Rating - Snap Action Switch 5 A @ 28 V, Contact Form- Switches 1NO, Height - Snap Action Switch 2.06 in, Width - Snap Action Switch 0.8 in, Depth - Snap Action Switch 0.94 in, Electrical Connection - Snap Action Switch Lead Wires, Series K1006
