  9. Exhaust Fan, 48 In, Less Drive Package
Shop All Belt Driven Exhaust Fans
Dayton

Exhaust Fan, 48 In, Less Drive Package

product price: $976.99
/ea
Item requires special delivery charges. A $80.00 per item surcharge will be applied.
Free 30-Day Returns

Key Features

  • Type Standard Duty Belt Drive Less Drive Package
  • Blade Dia. 48 in
  • CFM Range 15,009 to 31,442
  • Exhaust/Supply Fan Motor HP 1/3 to 3
  • Drive Package With Motor Included No
See all product information

Product Information

Dimensions

Blade Dia. 48 in
Dimension C (In.) 7 in
Shaft Dia. (In.) 1 1/4 in
Venturi Depth (In.) 7 in
Dimension F (In.) 48 1/2 in
Dimension B (In.) 23 1/2 in
Dimension A (In.) 54 in
Flange Depth (In.) 2 in
Bearing Size (In.) 1 1/4 in
Height (In.) 54 in
Venturi Clearance Dia. (In.) 48 1/2 in
Max. Depth (In.) 23 1/2 in
Width (In.) 54 in
Dimension E (In.) 16 1/2 in
Dimension D (In.) 2 in
Overall Width 54 in
Overall Height 54 in
For Cut-Out Height 50 1/2 in
Overall Depth 23 1/2 in
Flange Depth 2 in
Venturi Diameter 48 1/2 in
Overall Diameter 48 in
For Cut-Out Width 50 1/2 in
Venturi Depth 7 in
Shaft Diameter 1 1/4 in
For Cut-Out Diameter 50 1/2 in
Flange Width 54 in
Bearing Size 1 1/4 in
Blade Diameter 48 in
Manufacturer Warranty Length 1 yr

Details

Exhaust/Supply Fan Item Exhaust Fan
Type Standard Duty Belt Drive Less Drive Package
CFM Range 15,009 to 31,442
Exhaust/Supply Fan Motor HP 1/3 to 3
Drive Package With Motor Included No
Requires Wall Collar and Shutter For New Installation
Wall Collar Stock No. 1WBV5
Number of Blades 6
Item Exhaust Fan
Mounting Position Horizontal or Vertical
Frame Material Steel
Propeller Material Steel
Drive Package Included No
Galvanized Wall Shutter No. 1C211
Weatherhood No. 1WBW4
Max. Ambient Temp. (F) 104 Degrees F
Bearing Type Regreasable Pillow Block
Aluminum Wall Shutter No. 3C312
Wall Housing Item No. 3FKG3
RPM Range 295 to 618
Agency Compliance UL And C-UL Listed
Intake Guard No. 1WBU7
Fiberglass Wall Shutter No. 5C220
Standards AMCA Air and Sound, UL/cUL 705
Method of Construction Stamped
For Minimum Motor Horsepower 1/3 hp
Minimum Airflow 15,009 cfm
For Maximum Motor Speed 618 RPM
Fan Style Panel
Mounting Orientation Horizontal or Vertical
Blade Material Steel
Frame Finish Zinc-Plated
Ventilation Type Exhaust
Maximum Ambient Operating Temperature 104 Degrees F
Maximum Inlet Temperature 104 Degrees F
For Minimum Motor Speed 295 RPM
Maximum Airflow 31,442 cfm
Includes Motor No
Guard Type None
Blade Finish Galvanized
For Maximum Motor Horsepower 3 hp
Assembled Unassembled
Maximum Static Pressure 0.75 in wg

Description

Exhaust Fan, Assembled Unassembled, Blade Diameter 48 in, Blade Material Steel, Frame Material Steel, For Maximum Motor Horsepower 3 hp, For Maximum Motor Speed 618 RPM, For Minimum Motor Horsepower 1/3 hp, For Minimum Motor Speed 295 RPM, Maximum Airflow 31,442 cfm, Maximum Static Pressure 0.75 in wg, Minimum Airflow 15,009 cfm, For Cut-Out Height 50 1/2 in, For Cut-Out Width 50 1/2 in, For Cut-Out Diameter 50 1/2 in, Guard Type None, Method of Construction Stamped, Number of Blades 6
