Dayton HVAC Motor, 1/100 HP, 1550 rpm, 115V, 3.3 71732298M - main

HVAC Motor, 1/100 HP, 1550 rpm, 115V, 3.3

  • Mfr # 71732298M

  • Zoro # G0513782

product price:  $64.89
/ea

Key Features

Voltage
115V AC
Nameplate RPM
1,550
Motor Enclosure Design
Totally Enclosed Air-Over
Number of Speeds
1
HP
1/100
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
71732298M
Zoro #
G0513782
UPC #
-
Country of Origin
Mexico

Dimensions

Body Dia.
3 5/16 in
Length Less Shaft
2 7/8 in
Shaft Dia.
1/4 in
Shaft Length
2 3/8 in
Cord Length
12 in

Details

Voltage
115V AC
Nameplate RPM
1,550
Motor Enclosure Design
Totally Enclosed Air-Over
Number of Speeds
1
HP
1/100
RPM Range
1,501-1,600
Footnotes
Mechanically reversible
Motor Service Factor
1
Stud/Base Mtg. Pattern
2-7/8 in
Motor Bearings
Sleeve
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Motor Thermal Protection
Auto
Max. Ambient Temp.
40 Degrees C
Full Load Amps
0.6 A
Frame
3.3
Mounting Pattern
2-7/8
Motor Application
HVAC/R
Motor Shaft Design
Flat
Number of Shafts
1
Standards
CSA Certified, UL Recognized
Motor Design
Shaded Pole
Hz
60 Hz
Ins. Class
A
Application
OEM and Replacement Use In A Wide Variety of Fan and Blower
Motor Shaft Rotation
CWSE
Duty
Continuous
Motor Mounting Type
Ring/Stud
Item
HVAC Motor
Mounting Stud Location
2/Both Ends
Phase
Single
No. of Speeds
1
Motor Sub Application
Direct Drive Fan/Blower
Capacitor Required
No
Usable @ 200V
No
Duty Cycle
Continuous
Usable @ 208V
No
Motor Mounting Position
All Angle
Mounting Stud Pattern
2 7/8 in
Mounting
Stud
Type
OEM Replacement

Description

HVAC Motor, Single Phase, Motor Design Shaded Pole, 1/100 hp HP, Nameplate RPM 1,550 RPM, No. of Speeds 1, Voltage 115V AC, 0.60 A Full Load Amps, 3.3 Frame, Output Watts 7.4 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class A, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CWSE, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Stud
