  11. HVAC Motor, 1/70 HP, 1550 rpm, 115V, 3.3
Dayton HVAC Motor, 1/70 HP, 1550 rpm, 115V, 3.3 71637607M - main

HVAC Motor, 1/70 HP, 1550 rpm, 115V, 3.3

  • Mfr # 71637607M

  • Zoro # G0408423

product price: $64.69
/ea

Key Features

Voltage
115V AC
Nameplate RPM
1,550
Motor Enclosure Design
Totally Enclosed Air-Over
Number of Speeds
2
HP
1/70
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
71637607M
Zoro #
G0408423
UPC #
-
Country of Origin
Mexico

Dimensions

Length Less Shaft
2 7/8 in
Body Dia.
3 5/16 in
Shaft Dia.
1/4 in
Cord Length
12 in
Shaft Length
2 1/2 in

Details

Voltage
115V AC
Nameplate RPM
1,550
Motor Enclosure Design
Totally Enclosed Air-Over
Number of Speeds
2
HP
1/70
RPM Range
1,501-1,600
Item
HVAC Motor
Motor Mounting Type
Ring/Stud
Motor Thermal Protection
Auto
Motor Shaft Design
Flat
Motor Design
Shaded Pole
Mounting Stud Location
2/Both Ends
Motor Service Factor
1
Stud/Base Mtg. Pattern
2-7/8 in
Duty
Continuous
Motor Sub Application
Direct Drive Fan/Blower
Frame
3.3
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Number of Shafts
1
Application
OEM and Replacement Use In A Wide Variety of Fan and Blower
Motor Application
HVAC/R
Max. Ambient Temp.
40 Degrees C
Ins. Class
B
No. of Speeds
2
Hz
60 Hz
Motor Shaft Rotation
CWSE
Full Load Amps
0.65 A
Phase
Single
Mounting Pattern
2 7/8
Motor Bearings
Sleeve
Capacitor Required
No
Mounting Stud Pattern
2 7/8 in
Motor Mounting Position
All Angle
Usable @ 200V
No
Usable @ 208V
No
Duty Cycle
Continuous
Mounting
Stud
Type
OEM Replacement

Description

HVAC Motor, Single Phase, Motor Design Shaded Pole, 1/70 hp HP, Nameplate RPM 1,550 RPM, No. of Speeds 2, Voltage 115V AC, 0.65 A Full Load Amps, 3.3 Frame, Output Watts 11 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CWSE, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Stud
