Shop DAYTON

Motor, PSC, 1/8 HP, 1725 RPM, 115V, 48, TEAO

  • Mfr # 4YY56

  • Zoro # G1842531

product price:  $165.99
/ea
Free Shipping & Returns

Key Features

Motor Shaft Rotation
CWLE
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Replacement For
4YC86
RPM Range
1,701-1,800
Shaft Length
4 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
4YY56
Zoro #
G1842531
UPC #
190735339640
Country of Origin
Multiple

Dimensions

Shaft Length
4 1/2 in
Length Less Shaft
3 3/4 in
Shaft Dia.
1/2 in
Body Dia.
5 5/8 in
Bolt Circle Dia.
5 1/8 in
Overall Length
8 29/32 in
Body Diameter
5.6 in
Frame Size
48YZ
Shaft Diameter
1/2 in
Bolt Circle Diameter
5 1/8 in

Details

Motor Shaft Rotation
CWLE
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Replacement For
4YC86
RPM Range
1,701-1,800
Mounting Stud Location
4/Opposite Shaft End
Motor Mounting Position
All Angle
Duty
Continuous
Frame
48YZ
Capacitor Required
Capacitor Included
Motor Application
HVAC/R
Standards
CSA Certified, UL Recognized
Ins. Class
B
HP
1/8
Motor Mounting Type
Ring/Stud
Full Load Amps
1.7 A
Voltage
115V AC
Item
Fan and Blower Motor
No. of Speeds
1
Nameplate RPM
1,750
Max. Ambient Temp.
40 Degrees C
Phase
Single
Motor Thermal Protection
Auto
Hz
60 Hz
Motor Sub Application
Direct Drive
Motor Service Factor
1
Includes
4 MFD 370VAC Capacitor
Motor Shaft Design
Flat
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Design
Permanent Split Capacitor
Application
Fan/Blower
Motor Bearings
Ball
Stud Quantity
4
Usable @ 208V
Not Usable at 208V
Usable @ 200V
Not Usable at 200V
Number of Shafts
1
Duty Cycle
Continuous
Conduit Box Position
F3
Number of Speeds
1
Mounting
Stud
Bearing Type
Ball
Nameplate Service Factor @ 60 Hz
1
Sub Application
Ventilator
Frame Material
Steel
Full Load Current @ 60 Hz
1.7 A
Frequency
60 Hz
Mounting Position
All Angle
Ambient Temperature - Maximum
40 Degrees C
Product Type
Fan and Blower Motor
Motor Enclosure Type
Totally Enclosed Air-Over
Insulation Class
B
Shaft Design
Flat
Drive Type
Direct Drive

Description

Fan and Blower Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/8 hp HP, Nameplate RPM 1,750 RPM, No. of Speeds 1, Voltage 115V AC, 1.7 A Full Load Amps, 48YZ Frame, 60 Hz Hz, Replacement For 4YC86, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CWLE, Motor Enclosure Design Totally Enclosed Air-Over
