Shop DAYTON

Sprinkler Pump, 2 hp, 208 to 240/480V AC, 3 Phase

  • Mfr # 5UPW8

  • Zoro # G2059942

product price:  $1,210.99
/ea
Free Shipping & Returns

Key Features

Pressure Pump Type
Centrifugal Pump
HP - Pumps
2 hp
Inlet
2"
Voltage - Pumps
208 to 240/480V AC
Outlet
2"
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
5UPW8
Zoro #
G2059942
UPC #
190735352038
Country of Origin
China

Dimensions

Outlet Size - Pumps
2 in NPT
Inlet Size - Pumps
2 in NPT
Length
19 3/4 in
Width
11 1/4 in
Height
13 3/4 in
Manufacturers Warranty Length
1 yr
Overall Length
19.6 in
Overall Width
11.42 in
Overall Height
13.87 in
Manufacturer Warranty Length
1 yr
Compatible Intake Pipe Size
2 in
Compatible Discharge Pipe Size
2 in
Inlet Diameter
2 in
Motor Frame Size
56J
Discharge Diameter
2 in
Wire Rope Length
19.6 in

Details

Item
Sprinkler Pump
Pressure Pump Type
Centrifugal Pump
HP - Pumps
2 hp
Inlet
2"
Voltage - Pumps
208 to 240/480V AC
Outlet
2"
Phase - Pumps
3
HP
2
Wetted Materials
SS,Viton,Carbon,Ceramic, Thermoplastic
Voltage
208-230/460
Seal Material
Carbon, Ceramic, Stainless Steel, Viton
Inlet (In.)
2
Suction Lift
25 ft
Motor Enclosure - Pumps
Totally Enclosed Fan-Cooled
Max. Pressure - Pumps
58 psi
Housing Material - Pumps
Thermoplastic
Best Efficiency GPM @ Head
47 @ 70 FT.
GPM @ 40 PSI
34
Includes
Manual
Amps
9.0-8.8/4.4
Phase
Three
Motor Type
3-Phase
Port Rotation
90 Degrees Increments
Hz
60
Impeller Material
Noryl
GPM @ 10 PSI
69
GPM @ 50 PSI
14
GPM @ 25 PSI
53
Impeller Type
Closed
GPM @ 45 PSI
24
Bearing Type
Double Shielded Pre Lubricated Ball
GPM @ 20 PSI
59
Max. Pressure
58 psi
For Use With
Nonflammable Liquids Compatible with Pump Component Materials
GPM @ 15 PSI
64
Motor Enclosure
Totally Enclosed Fan Cooled
Duty
Continuous
Max. Specific Gravity
1
Housing Material
Thermoplastic
GPM @ 35 PSI
40
Agency Compliance
Motor Only CSA
Max. Head
134 ft
Features
Stainless Steel Fasteners and Inserts
Frame
56J
Max. Case Pressure
138 psi
GPM @ 30 PSI
47
Stages
1
Inlet Pressure
22 psi
Standards
CUS
Shaft Material
Stainless Steel
For Use With Potable Systems
No
Thermal Overload Protection
No
Shut Off Pressure (Maximum)
58 psi
Maximum Flow Rate
69 gpm
Flow Rate @ 50 psi
14 gpm
Nameplate Voltage
230/460V AC
Flow Rate @ 10 psi
90 gpm
Duty Cycle
Continuous
Motor Frame Designation
56J
Best Efficiency Flow
47 gpm
Horsepower
2 hp
Specific Gravity (Maximum)
1
Priming
Self-Priming
Flow Rate @ 20 psi
77 gpm
Discharge Rotation
90 Degrees Increments
Compatible with Media Type
Non-Flammable Liquids
Discharge Type
NPT
Wetted Material
Carbon, Ceramic, Stainless Steel, Thermoplastic, Viton
Maximum Feet of Head
134 ft
Flow Rate @ 15 psi
77 gpm
Suction Lift (Maximum)
20 ft
Frequency
60 Hz
Intake Type
NPT
Flow Rate @ 40 psi
44 gpm
Motor Ambient Temperature (Maximum)
104 Degrees F
Case Pressure (Maximum)
138 psi
Maximum RPM
3,450 RPM
Flow Rate @ 30 psi
61 gpm
Best Efficiency Head
70 ft
Pump Housing Material
Thermoplastic
Case Pressure - Maximum
138 psi
Pump Drive Configuration
Frame-Mounted
Shaft Seal Material
Carbon/Ceramic/FKM/Stainless Steel
Number of Stages
1
Electrical Connection Type
Hardwired
Shut Off Pressure - Maximum
58 psi
Media Temperature - Minimum
40 Degrees F
Flow Rate (Maximum)
69 gpm
Motor Design
Three-Phase
Ambient Temperature - Minimum
40 Degrees F
Chemical Compatibility
Non-Flammable Liquids
Feet of Head (Maximum)
134 ft
Ambient Temperature - Maximum
104 Degrees F
Pumping Application
Irrigation, Sprinkler Systems, Spraying Systems
Full Load Current
5.6/2.8A
Pump Design
End Suction
Media Temperature - Maximum
180 Degrees F

Description

Sprinkler Pump, Phase Three, Pump Housing Material Thermoplastic, Horsepower 2 hp, Nameplate Voltage 230/460V AC, Suction Lift (Maximum) 20 ft, Flow Rate @ 10 psi 90 gpm, Flow Rate @ 20 psi 77 gpm, Maximum Feet of Head 134 ft, Shut Off Pressure (Maximum) 58 psi, Compatible Intake Pipe Size 2 in, Compatible Discharge Pipe Size 2 in, Intake Type NPT, Motor Enclosure Totally Enclosed Fan Cooled, Flow Rate @ 30 psi 61 gpm, Flow Rate @ 40 psi 44 gpm, Priming Self-Priming, Best Efficiency Flow 47 gpm
