Shop DAYTON

Three-Phase General Purpose Motor, 1 HP, 182/4 Frame, 230/460V AC Voltage, 1170 Nameplate RPM

  • Mfr # 36VE88

  • Zoro # G1860708

product price:
$
602.99
/ea
Free Shipping & Returns

Key Features

Nameplate RPM
1170
Voltage
230/460V AC
Motor Mounting Type
Rigid Base
Full Load Amps
3.2/1.6 A
Frame
182/4
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
36VE88
Zoro #
G1860708
UPC #
190735275221
Country of Origin
Mexico

Dimensions

Length Less Shaft
13 9/16 in
Overall Length
15 7/8 in
Shaft Dia.
7/8 in
Shaft Length
2 1/4 in
Manufacturers Warranty Length
1 yr
Body Diameter
8.11 in
Shaft Diameter
7/8 in
Frame Size
182-4
Wire Rope Length
15 7/8 in
Length
15 7/8 in

Details

Item
General Purpose Motor
HP
1
Nameplate RPM
1170
Voltage
230/460V AC
Motor Mounting Type
Rigid Base
Full Load Amps
3.2/1.6 A
Frame
182/4
Motor Bearings
Ball
Motor Service Factor
1.15
Motor Design
Three-Phase
Motor Enclosure Design
Totally Enclosed Fan Cooled
RPM Range
1,101-1,200
Phase
Three
No. of Speeds
1
Motor Application
General Purpose
Motor Shaft Rotation
CW/CCW
Voltage Compatibility
200-230/460V AC, 208-230/460V AC, 460V AC
Hz
60 Hz
Ins. Class
F
Max. Ambient Temp.
40 Degrees C
Motor Frame Material
Steel
Motor Mounting Position
Horizontal
Motor Shaft Design
Keyed
Nominal Efficiency
82.5 %
Standards
CE, CSA, UL
CC Number
CC029A
Inverter Rated
Yes
Motor Thermal Protection
None
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Includes
Shaft Key
Green Certification or Other Recognition
NEMA Premium(R) Rated
Footnotes
2,15,53
Capacitor Required
No
Duty Cycle
Continuous
Mounting Position
Horizontal
Manufacturers Warranty
1 yr
Usable @ 200V
Not Usable at 200V
Efficiency Rating
NEMA Premium Efficiency
Bearing Lubrication Type
Permanently Lubricated
Constant Torque Rating
4:1
Conduit Box Location
Exterior
Frequency
60 Hz
Insulation Class
F
Inverter Rating
Inverter Rated
Full Load Current @ 60 Hz
3.3/1.6 A
Frame Material
Steel
Weight
27 1/8 kg
NEMA Design Class
B
Number of Speeds
1
Shaft Design
Keyed
Ambient Temperature - Maximum
40 Degrees C
Variable Torque Rating
10:1
Application
General Purpose
Product Type
General Purpose Motor
Bearing Type
Ball
Motor Enclosure Type
Totally Enclosed Fan Cooled
Usable @ 208V
Not Usable at 208V
Nameplate Service Factor @ 60 Hz
1.15
Bearing Protection Type
Shaft Slingers

Description

General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 HP, Nameplate RPM 1170, Frame 182/4, Voltage 230/460V AC, 60 Hz Hz, Three Phase, Full Load Amps 3.2/1.6 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 82.5 Percent, Continuous Duty, 1,101-1,200, CE, CSA, UL
