  11. Tool Motor, 2-Shaft, 3/4hp, 1750rpm, 115/230
Dayton Tool Motor, 2-Shaft, 3/4hp, 1750rpm, 115/230 4K783BB - main

Tool Motor, 2-Shaft, 3/4hp, 1750rpm, 115/230

  • Mfr # 4K783BB

  • Zoro # G1422976

product price: $445.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start
Motor Enclosure Design
Open Drip Proof
HP
3/4 hp
Nameplate RPM
1,750 RPM
Frame
56
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
4K783BB
Zoro #
G1422976
UPC #
-
Country of Origin
Mexico

Dimensions

Shaft Length
1 7/8 in
Length Less Shaft
8 7/16 in
Shaft Dia.
5/8 in
Overall Length
12 5/8 in

Details

Item
Power Tool Motor
Motor Design
Capacitor-Start
Motor Enclosure Design
Open Drip Proof
HP
3/4 hp
Nameplate RPM
1,750 RPM
Frame
56
Voltage
115/230V AC
Full Load Amps
11.0/5.5 A
Motor Mounting Type
Rigid Base
RPM Range
1,701-1,800
Standards
CSA Certified (701887), UL Component Recognized (E47479)
Phase
Single
Motor Service Factor
1
Motor Thermal Protection
None
Hz
60 Hz
Motor Shaft Rotation
CW/CCW
Motor Application
Power Tools
Ambient Temperature
40 Degrees C
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 230V AC, 240V AC
Ins. Class
A
Motor Bearings
Ball
Usable @ 200V
Not Usable at 200V
Motor Shaft Design
Keyed
No. of Speeds
1
Usable @ 208V
Not Usable at 208V
Max. Ambient Temp.
40 Degrees C
Number of Shafts
2
Motor Frame Material
Steel
Motor Mounting Position
Horizontal
On/Off Switch
On/Off Switch Not Included
Duty Cycle
Continuous

Description

Power Tool Motor, Single Phase, Motor Design Capacitor-Start, 3/4 hp HP, Nameplate RPM 1,750 RPM, No. of Speeds 1, 115/230V AC Voltage, Full Load Amps 11.0/5.5 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class A, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Rigid Base
