Shop DWYER INSTRUMENTS

Pressure Switch, Standard, SPDT, 1/8" FNPT, 0.15 to 0.50 in H2O Range

  • Mfr # 1950G-0-B-24-NA
  • Zoro # G307143377
product price:
$
615.99
/ea
Free Shipping & Returns

Key Features

Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
0.15 to 0.5"wc
Factory On Setting
0.15"wc
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
1950G-0-B-24-NA
Zoro #
G307143377
UPC #
-
Country of Origin
United States
Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
0.15 to 0.5"wc
Factory On Setting
0.15"wc
Factory Off Setting
0.5"wc
Standards
ATEX, CE, CSA, FM, IECEx, UL
Features
Compatible with natural gas; External set point screw provides easy access that simplifies making adjustments without opening or disassembling enclosure; Easily accessible electrical connection simplifies the installation
Process Connections
1/8" female NPT.
Pressure Limits
45" w.c. (11.2 kPa) continuous; 10 psig (68.95 kPa) surge.
Agency Approvals
ATEX, CE, CSA, FM, IECEx, UL.
Temperature Limits
0 to 140°F (-17 to 60°C). Note: Set point drift may occur with ambient temperature changes.
Service
Air and compatible combustible gases.
Switch Type
1 Form C relay (SPDT).
Power Requirements
24 VDC ±10%. 120 or 240 VAC ±10% optional.
Set Point Adjustment
Screw type on top of housing.
Mounting Orientation
Vertical
Pressure Setpoint Type
Adjustable
Pressure Type
Differential
Minimum Pressure Setting
0.06 in wc
Housing Type
NEMA-3 Enclosure
IP Rating
IP54
Maximum Pressure Setting
0.11 in wc
Minimum Operating Temperature
0 Degrees F
Maximum Differential Pressure Setting
0.5 in wc
Minimum Differential Pressure Setting
0.15 in wc
Mounting Hole Center to Center Distance
4 7/8 in
Number of Switches
1
Input Voltage
24V DC
Electrical Rating
10 A @ 120/240 V AC and 28 V DC, 50 mA Resistive @ 125 V DC
Housing Material
Aluminum
Reset Type
Automatic Reset
Product Type
Pressure Switch
Sample Line Connector Type
NPT
Electrical Connection Type
Screw Terminals
Maximum Operating Temperature
140 Degrees F
Maximum Pressure Rating
10 psig
Weight
3.3 lb

Dimensions

Overall Depth
5 11/16 in
Overall Height
5 11/16 in
Mounting Hole Diameter
1/4 in
Sample Line Connection Size
1/8 in
Overall Width
5 11/16 in

Description

Pressure Switch, Contact Form SPDT, Electrical Connection Type Screw Terminals, Electrical Rating 10 A @ 120/240 V AC and 28 V DC, 50 mA Resistive @ 125 V DC, Housing Material Aluminum, Housing Type NEMA-3 Enclosure, IP Rating IP54, Input Voltage 24V DC, Maximum Differential Pressure Setting 0.5 in wc, Maximum Operating Temperature 140 Degrees F, Maximum Pressure Rating 10 psig, Maximum Pressure Setting 0.11 in wc, Minimum Differential Pressure Setting 0.15 in wc
