  6. Surge Protection Device, 1 Phase, 120VAC, 1 Poles, 2

This item is Discontinued.

Eaton Bussmann Surge Protection Device, 1 Phase, 120VAC, 1 Poles, 2 BSPM1120S2GR

Surge Protection Device, 1 Phase, 120VAC, 1 Poles, 2 (Discontinued)

  • Mfr # BSPM1120S2GR
  • Zoro # G4419895
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
BSPM1120S2GR
Zoro #
G4419895
UPC #
051712372374
Country of Origin
Germany

Dimensions

Length
3.93"
Depth
2.56"
Width
0.71"
Length (Straight Wireway)
3.93 in

Details

Item
Surge Protection Device
Mounting Style
DIN Rail
Phase
1
Voltage
120VAC
Number of Poles
1
Voltage Protection Rating
1000V (L-G, L-N)
Number of Wires
2
Modes of Protection
L-G, L-N
Max. Surge Current per Mode
40kA
Max. Surge Current per Phase
40kA
Nominal Discharge Current
20kA
Short Circuit Current Rating
200kA
Modular
Yes
Filtering
No
Max. Continuing Operating Voltage
275 V AC
IP Rating
20
Enclosure Material
Thermoplastic
Wire Gauge
14 to 2 AWG
Includes
Installation Instructions
Standards
UL 1449 3rd Edition, cURus
Filtering / Nonfiltering
Nonfiltering
Modular / Nonmodular
Modular

Description

Surge Protection Device, Depth 2.56 in, Enclosure Material Thermoplastic
