Eaton Bussmann Surge Protection Device, 1 Phase, 24V, 4 Poles, 4 Wires BSPD24DING - main

Surge Protection Device, 1 Phase, 24V, 4 Poles, 4 Wires

  • Mfr # BSPD24DING

  • Zoro # G6149254

product price:  $310.99
/ea
Free Shipping & Returns

Key Features

Mounting Style
DIN Rail
Phase
1
Voltage
24V
Number of Poles
4
Voltage Protection Rating
102V (L-L), 66V (L-G)
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
BSPD24DING
Zoro #
G6149254
UPC #
051712398893
Country of Origin
Germany

Dimensions

Length
3.54 in
Depth
2.83 in
Width
0.47 in

Details

Item
Surge Protection Device
Mounting Style
DIN Rail
Phase
1
Voltage
24V
Number of Poles
4
Voltage Protection Rating
102V (L-L), 66V (L-G)
Number of Wires
4 Wires
Modes of Protection
L-G, L-L
Max. Surge Current Per Mode
20kA
Max. Surge Current per Mode
2.5 kA
Max. Surge Current per Phase
2.5 kA
Nominal Discharge Current
10 kA
Short Circuit Current Rating
24 KA
Modular
Yes
Filtering
No
Max. Continuing Operating Voltage
33V DC
IP Rating
IP20
Enclosure Material
Polyamide
Wire Gauge
28 to 12 AWG
Modular / Nonmodular
Modular
Standards
EN 61643-21, IEC 61643-21, UL 497B
Lightning Impulse Current
10 kA
System Connection
Series
Amps
0.75 A
Min. Operating Temp.
-40 Degrees F
Max. Operating Temp.
176 Degrees F
Color
Gray
Basic Material
Nonmetallic
Type
Surge arrestor
Includes Surge Counter
No
Mounting Method
DIN rail L-G
Operating Temperature
-40 to 80 °C
Certifications
UL 94V0
Used with
Data signal
Special Features
Technology type spark-gap

Description

Universal Surge Protection Device, Nonmetallic, Gray, Amps 0.75 A, Depth 2.83 in, Enclosure Material Polyamide
