Shop EATON

Limit Switch

  • Mfr # E50AR1P5
  • Zoro # G723353619
product price:
$
898.99
/ea
Free Shipping & Returns

Key Features

Standards
CE, CSA, RoHS, UL Listed
IP Rating
IP67
Body Material
Zinc
Electrical Connection
5-Pin Mini Male Connector
Lamp Type
No Lamp Module Included
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
E50AR1P5
Zoro #
G723353619
UPC #
782113370859
Country of Origin
Mexico

Dimensions

Overall Width
2.41 in
Manufacturer Warranty Length
1 yr
Overall Height
5.23 in
Overall Depth
1.54 in

Details

Standards
CE, CSA, RoHS, UL Listed
IP Rating
IP67
Body Material
Zinc
Electrical Connection
5-Pin Mini Male Connector
Item
Limit Switch
Lamp Type
No Lamp Module Included
Contact Action
Snap-Action
Mounting Hole Horizontal Center to Center Distance
30 mm
Arm Adjustability
Fixed
Boot Sealed Actuator
Boot Included
Directional Movement
CCW/CW
Actuator Style
Roller-Lever Arm
Operating Temperature - Minimum
10 Degrees F
DC Contact Rating
1 A @ 250 V
NEMA Enclosure Rating
1, 13, 3, 3S, 4, 4X, 6, 6P
Body Configuration
Plug-In
Mounting Hole Vertical Center to Center Distance
60 mm
AC Contact Rating
10 A @ 240 V
Includes Actuator
No Actuator Included
Operating Temperature - Maximum
200 Degrees F
Series
E50
Contact Form
1NO/1NC

Description

Limit Switch, Electrical Connection 5-Pin Mini Male Connector, IP Rating IP67
